Airtac APH Hex Head Connector APH10-01
2. Superior flow performance achieving equivalent flow capacity to tubing inner diameter;
3. Tool-free tubing insertion/extraction with secure, durable, and leak-proof connections;
4. Threads pre-coated with sealant; M5 metric threads integrate sealing washers for leak-resistant threaded joints;
5. Nickel-plated brass body ensures corrosion resistance and contamination prevention, expanding application versatility.
Category: Hex Nipple Connectors, Brand: AIRTAC, Series: APH
AirTAC APH10-01 Hexagon Connector Specifications
- Model: APH10-01
- Type: Straight thread hexagon connector (male thread)
- Thread standard: Metric (M5×0.8)
- Port size: 10mm tube OD compatible
- Max working pressure: 1.5 MPa (15 bar)
- Burst pressure: ≥4.5 MPa
- Material: Brass CW617N (chrome-plated surface)
- Seal type: EPDM O-ring (standard), NBR optional
- Temperature range: -20℃ to 150℃ (with EPDM seal)
- Thread engagement length: 8mm
- Weight: 12.5g ±0.3g
- Dimensions: 19mm(L) × 10mm(W) × 10mm(H)
- Surface hardness: HV0.3 ≥450
- Vibration resistance: 10-2000Hz, 15G acceleration
Precision-machined hexagon connector featuring leak-proof tapered thread design with dual sealing surfaces. The chrome-plated brass construction provides corrosion resistance in humid environments. Includes anti-vibration grooves for secure tube retention. Compatible with polyurethane/nylon tubing (hardness 90±5 Shore A).
- Pneumatic cylinder port connections
- Air preparation unit assemblies
- Industrial robot end-effector air lines
- CNC machine tool pneumatic circuits
- Medical gas delivery systems
Installation guidance:
Apply 0.5-0.8Nm torque during installation using 8mm wrench.
Always use thread sealant on male threads (PTFE tape not recommended).
Maximum 3 re-tightening cycles allowed after initial installation.
| Property | Property Value |
|---|---|
| sku | APH10-01 |
