Airtac APH Hex Head Connector APH10-02
2. Superior flow performance achieving equivalent flow capacity to tubing inner diameter;
3. Tool-free tubing insertion/extraction with secure, durable, and leak-proof connections;
4. Threads pre-coated with sealant; M5 metric threads integrate sealing washers for leak-resistant threaded joints;
5. Nickel-plated brass body ensures corrosion resistance and contamination prevention, expanding application versatility.
Category: Hex Nipple Connectors, Brand: AIRTAC, Series: APH
AirTAC APH Series Hexagon Connector APH10-02 Technical Details
- Model: APH10-02
- Type: Pneumatic hexagon threaded connector
- Thread specification: PT1/8 (BSPP 1/8") female threads
- Applicable tube OD: Ø10mm (flexible pneumatic tubing)
- Material: Brass (nickel-plated surface)
- Pressure range: 0.05-1.0 MPa
- Temperature range: -5℃ to 80℃
- Seal material: NBR (Nitrile rubber)
- Hexagon size: 17mm across flats
- Weight: 28g ±1g
- Dimensions: 32mm(L) × 17mm(W) × 17mm(H)
- Surface roughness: Ra ≤3.2μm
- Proof pressure: 1.5 MPa (150% of max working pressure)
High-strength compression fitting with anti-vibration hexagonal design, featuring a 360° rotatable collar for flexible tubing alignment. The electroplated surface provides corrosion resistance in humid environments. Includes integrated O-ring for leak-free connections up to 1 million cycles.
- Primary use: Branch connections in pneumatic circuits
- Ideal for space-constrained installations due to compact profile
- Common in CNC machine tooling air lines
- Food packaging equipment (NSF-certified material options available)
- Laboratory pneumatic control systems
Maintenance tip:
Apply pneumatic sealant tape clockwise on male threads (2-3 wraps max).
Torque specification: 12-15 N·m. Avoid overtightening to prevent thread deformation.
- Direct pairing with AirTAC PIS series push-in fittings
- Matched with ISO 1179-2 standard adapters
- Works with all 10mm OD polyurethane/nylon tubing
| Property | Property Value |
|---|---|
| sku | APH10-02 |
