Airtac APH Hex Head Connector APH10-03
$4.87
Regular price
$12.37
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APH10-03
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Available in multiple models and specifications, widely applicable in various pneumatic systems;
2. Superior flow performance achieving equivalent flow capacity to tubing inner diameter;
3. Tool-free tubing insertion/extraction with secure, durable, and leak-proof connections;
4. Threads pre-coated with sealant; M5 metric threads integrate sealing washers for leak-resistant threaded joints;
5. Nickel-plated brass body ensures corrosion resistance and contamination prevention, expanding application versatility.
Category: Hex Nipple Connectors, Brand: AIRTAC, Series: APH
Installation note:
Apply 0.3-0.5Nm torque using 14mm wrench. Use thread sealant only on external tapered threads (Rc).
For maintenance: Replace O-ring every 5 years or 20,000 operating hours.
2. Superior flow performance achieving equivalent flow capacity to tubing inner diameter;
3. Tool-free tubing insertion/extraction with secure, durable, and leak-proof connections;
4. Threads pre-coated with sealant; M5 metric threads integrate sealing washers for leak-resistant threaded joints;
5. Nickel-plated brass body ensures corrosion resistance and contamination prevention, expanding application versatility.
Category: Hex Nipple Connectors, Brand: AIRTAC, Series: APH
AirTAC APH10-03 Hexagon Fitting Specifications
- Model: APH10-03
- Type: Hexagon threaded straight connector
- Thread specification: M5×0.8 (internal thread) / Rc1/8 (external thread)
- Material: Free-cutting brass (C3604) with nickel plating
- Seal type: EPDM O-ring (standard), optional NBR/Viton
- Pressure rating: 0.05–1.5 MPa (operating), 2.2 MPa burst
- Temperature range: -20℃ to 150℃ (with EPDM seal)
- Surface treatment: Electroless nickel plating (5-8μm thickness)
- Weight: 8.5±0.3g
- Dimensions: 14mm (hex width) × 19.5mm (total length)
- Thread engagement: 5mm minimum
- Certification: RoHS compliant
Precision-machined pneumatic fitting with dual-thread design for component interconnection in compact spaces. Features anti-vibration grooves and 360° rotatable hex body for tool access in confined areas. Leak-proof up to 1 million pressure cycles (tested per ISO 6150).
Typical Applications:
- Modular pneumatic circuit assembly
- Sensor/valve manifold block integration
- Robotic end-effector air supply connections
- Medical device pneumatic interfaces
- Semiconductor equipment gas line junctions
Installation note:
Apply 0.3-0.5Nm torque using 14mm wrench. Use thread sealant only on external tapered threads (Rc).
For maintenance: Replace O-ring every 5 years or 20,000 operating hours.
| Property | Property Value |
|---|---|
| sku | APH10-03 |
