Airtac APH Hex Head Connector APH10-M10
$4.36
Regular price
$11.86
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APH10-M10
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Available in multiple models and specifications, widely applicable in various pneumatic systems;
2. Superior flow performance achieving equivalent flow capacity to tubing inner diameter;
3. Tool-free tubing insertion/extraction with secure, durable, and leak-proof connections;
4. Threads pre-coated with sealant; M5 metric threads integrate sealing washers for leak-resistant threaded joints;
5. Nickel-plated brass body ensures corrosion resistance and contamination prevention, expanding application versatility.
Category: Hex Nipple Connectors, Brand: AIRTAC, Series: APH
Installation guidance:
Apply 12-15 N·m torque during assembly. Use thread sealant only on male threads,
avoiding contact with O-ring surfaces. Perform pressure test at 1.1× working pressure after installation.
2. Superior flow performance achieving equivalent flow capacity to tubing inner diameter;
3. Tool-free tubing insertion/extraction with secure, durable, and leak-proof connections;
4. Threads pre-coated with sealant; M5 metric threads integrate sealing washers for leak-resistant threaded joints;
5. Nickel-plated brass body ensures corrosion resistance and contamination prevention, expanding application versatility.
Category: Hex Nipple Connectors, Brand: AIRTAC, Series: APH
AirTAC APH Hexagon Connector APH10-M10 Technical Details
- Model: APH10-M10
- Thread type: Metric parallel (M)
- Port size: M10×1.0 (male thread)
- Body material: High-strength brass alloy (CuZn39Pb3)
- Surface treatment: Electroless nickel plating (5-8μm)
- Seal material: NBR (Nitrile) O-ring
- Pressure rating: 1.5 MPa (15 bar) maximum
- Temperature range: -20℃ to +80℃ (continuous use)
- Proof pressure: 3.0 MPa (30 bar)
- Thread tolerance: 6g per ISO 965-1 standard
- Weight: 18.5±0.3 grams
- Dimensions: 24mm (L) × 17mm (W) × 17mm (H)
- Hexagon size: 17mm AF (across flats)
- Flow coefficient (Cv): 0.25
- Certification: RoHS compliant
Precision-machined hexagon connector with integrated sealing groove, designed for leak-free pneumatic connections. Features corrosion-resistant nickel plating and anti-vibration thread design. Compatible with ISO 1179-2 standard ports.
Typical Applications:
- Pneumatic cylinder port connections
- Modular valve manifold assemblies
- Compressed air distribution systems
- Industrial automation tooling interfaces
- CNC machine pneumatic circuits
Installation guidance:
Apply 12-15 N·m torque during assembly. Use thread sealant only on male threads,
avoiding contact with O-ring surfaces. Perform pressure test at 1.1× working pressure after installation.
Compatible Accessories:
- AirTAC PUC series polyurethane tubing (ID 6mm)
- AS series air strainers (1/8" BSPP)
- APEM series push-to-connect fittings
| Property | Property Value |
|---|---|
| sku | APH10-M10 |
