Airtac APH Hex Head Connector APH10-M12
2. Superior flow performance achieving equivalent flow capacity to tubing inner diameter;
3. Tool-free tubing insertion/extraction with secure, durable, and leak-proof connections;
4. Threads pre-coated with sealant; M5 metric threads integrate sealing washers for leak-resistant threaded joints;
5. Nickel-plated brass body ensures corrosion resistance and contamination prevention, expanding application versatility.
Category: Hex Nipple Connectors, Brand: AIRTAC, Series: APH
AirTAC APH10-M12 Hexagon Connector Technical Details
- Model: APH10-M12
- Type: External hexagon threaded straight connector
- Thread specification: M12×1.5 (male thread)
- Material: Brass (nickel-plated surface)
- Temperature range: -20℃ to 80℃
- Operating pressure: 0.05-1.5 MPa
- Seal material: NBR (nitrile rubber)
- Installation torque: 20-25 N·m
- Protection rating: IP40
- Weight: 48±2g
- Dimensions: 30mm(L) × 19mm(W across flats) × 25mm(H)
- Tube compatibility: Ø10mm polyurethane/nylon tubing
Precision-machined pneumatic connector featuring anti-vibration hexagon design with dual O-ring seals. The chrome-plated brass construction ensures corrosion resistance in humid environments. Includes integrated flow path optimization for minimal pressure drop (ΔP ≤ 0.02 MPa at 0.5 MPa input).
- Requires 8mm hex wrench for installation
- Pre-lubricated seals (do not use silicone-based additives)
- Maximum angular misalignment tolerance: ±3°
- Re-torque after 500 operational hours
- Pneumatic cylinder port connections
- Compressed air distribution manifolds
- Food processing equipment (FDA-compliant variant available)
- Semiconductor manufacturing gas lines
- Robotic end-effector pneumatic networks
Critical note:
Always perform pressure testing at 1.25× system pressure before commissioning.
Avoid cross-threading - initial hand-tightening must achieve 3.5 full rotations.
| Property | Property Value |
|---|---|
| sku | APH10-M12 |
