Airtac APH Hex Head Connector APH10-M16
2. Superior flow performance achieving equivalent flow capacity to tubing inner diameter;
3. Tool-free tubing insertion/extraction with secure, durable, and leak-proof connections;
4. Threads pre-coated with sealant; M5 metric threads integrate sealing washers for leak-resistant threaded joints;
5. Nickel-plated brass body ensures corrosion resistance and contamination prevention, expanding application versatility.
Category: Hex Nipple Connectors, Brand: AIRTAC, Series: APH
AirTAC APH Hexagon Connector APH10-M16 Technical Details
- Model: APH10-M16
- Type: Hexagon Threaded Straight Connector (Male-Female)
- Thread Specification: M16×1.5 (Metric Fine Thread)
- Material: Lead-Free Brass CW617N
- Surface Treatment: Nickel Plating (3-5μm thickness)
- Pressure Rating: 0.2-1.5 MPa (29-217 PSI)
- Temperature Range: -20℃ to 120℃
- Seal Type: Integrated O-ring (NBR Material)
- Hex Size: 24mm AF (Across Flats)
- Weight: 38g ±2g
- Dimensions:
- Total Length: 32mm
- Thread Engagement Length: 13mm
- Body Diameter: 19mm
- Wrench Flat Thickness: 8mm
- Fluid Compatibility: Air, Water, Non-corrosive Gases
- Vibration Resistance: ≤10Hz @ 2mm amplitude
Precision-machined pneumatic connector featuring dual sealing structure with primary metal-to-metal thread seal and secondary NBR O-ring backup. The hexagonal body design allows 360° tool access for installation in confined spaces. Nickel plating enhances corrosion resistance in humid environments.
- Pneumatic cylinder port connections
- Modular pneumatic manifold systems
- Compressed air distribution lines
- Industrial robot end effector tooling
- CNC machine pneumatic circuits
Installation Guide:
Apply 2-3 N·m torque using 24mm wrench. For vertical downward ports,
use thread sealant (PTFE tape recommended). Avoid overtightening
to prevent O-ring compression set. Inspect seal annually in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | APH10-M16 |
