Airtac APH Hex Head Connector APH10-M20
2. Superior flow performance achieving equivalent flow capacity to tubing inner diameter;
3. Tool-free tubing insertion/extraction with secure, durable, and leak-proof connections;
4. Threads pre-coated with sealant; M5 metric threads integrate sealing washers for leak-resistant threaded joints;
5. Nickel-plated brass body ensures corrosion resistance and contamination prevention, expanding application versatility.
Category: Hex Nipple Connectors, Brand: AIRTAC, Series: APH
AirTAC APH Series Hex Locknut Fitting APH10-M20 Technical Details
- Full Model: APH10-M20
- Type: Hexagonal thread-to-tube connector
- Thread Specification: M20×1.5 external thread (ISO 1179 standard)
- Tube Compatibility: Ø10mm OD pneumatic tubing
- Material: Cold forged carbon steel (Zn-Ni alloy coating)
- Pressure Rating: 1.5 MPa (15 bar) maximum working pressure
- Burst Pressure: ≥4.5 MPa
- Temperature Range: -20℃ to 120℃ (continuous operation)
- Surface Hardness: 480-550 HV
- Thread Engagement: Minimum 5 full turns required
- Installation Torque: 35-45 N·m (dry)/25-35 N·m (lubricated)
- Weight: 82g ±2g
- Dimensions: 34mm(A/F) × 28mm(H) × 28mm(W) (across flats: 34mm)
- Seal Type: Integrated copper crush washer
- Vibration Resistance: 10-2000Hz, 15G acceleration
Heavy-duty pneumatic fitting with anti-vibration hexagonal design, featuring triple-sealing through precision machining (thread flank sealing + washer sealing + tube grip). The electroplated surface provides 720hr salt spray resistance. Internal flow path optimized for 25% reduced turbulence compared to standard fittings.
- High-pressure pneumatic lines in injection molding machines
- Vibration-prone connections in CNC tool changers
- Hydraulic test bench manifold assemblies
- Food processing equipment (compatible with NSF-H1 grease)
- Railway braking system tubing interfaces
Installation Protocol:
Use flank-drive wrench to prevent rounding. Apply thread sealant only on male threads,
avoiding contamination of washer surface. Re-torque after 50 thermal cycles in
high-temperature environments. Replace after 3 disassembly cycles.
| Property | Property Value |
|---|---|
| sku | APH10-M20 |
