Airtac APH Hex Head Connector APH12-M16
2. Superior flow performance achieving equivalent flow capacity to tubing inner diameter;
3. Tool-free tubing insertion/extraction with secure, durable, and leak-proof connections;
4. Threads pre-coated with sealant; M5 metric threads integrate sealing washers for leak-resistant threaded joints;
5. Nickel-plated brass body ensures corrosion resistance and contamination prevention, expanding application versatility.
Category: Hex Nipple Connectors, Brand: AIRTAC, Series: APH
AirTAC APH12-M16 Hexagon Connector Technical Details
- Model: APH12-M16 (Male Thread)
- Thread specification: M16×1.5 (ISO 1179 standard)
- Material: Lead-free brass CW617N
- Surface treatment: Electroless nickel plating (5-8μm)
- Max working pressure: 1.5 MPa (217 psi)
- Temperature range: -20℃ to 120℃ (continuous operation)
- Seal type: EPDM O-ring (standard), optional NBR/Viton
- Tightening torque: 30-35 N·m (lubricated condition)
- Proof pressure: 2.25 MPa (326 psi)
- Burst pressure: ≥3 MPa (435 psi)
- Weight: 28g ±2g
- Dimensions: 24mm (W across flats) × 18mm (H) × 22mm (L)
- Compatibility: Works with Φ12mm OD pneumatic tubing
- Certification: RoHS 2.0 compliant
Precision-machined hexagon connector featuring triple-seal structure (metal-to-metal seal + double O-rings) for leak-free performance in high-vibration environments. The 24mm wrench flats enable tool-assisted installation while maintaining compact dimensions. Nickel plating provides corrosion resistance in humid conditions.
- Robotic arm pneumatic circuits requiring vibration resistance
- CNC machine tool air supply connections
- Food processing equipment (EPDM seals for washdown areas)
- Railway braking systems (with anti-loosening design)
- Semiconductor manufacturing gas lines
Installation protocol:
Apply thread sealant to male threads (PTFE tape not recommended).
Use calibrated torque wrench for assembly - under-tightening causes leaks,
over-tightening may deform O-ring grooves. Perform pressure test at 1.1×
working pressure after installation.
