Airtac APH Hex Head Connector APH4-01
$3.32
Regular price
$10.82
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APH4-01
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Available in multiple models and specifications, widely applicable in various pneumatic systems;
2. Superior flow performance achieving equivalent flow capacity to tubing inner diameter;
3. Tool-free tubing insertion/extraction with secure, durable, and leak-proof connections;
4. Threads pre-coated with sealant; M5 metric threads integrate sealing washers for leak-resistant threaded joints;
5. Nickel-plated brass body ensures corrosion resistance and contamination prevention, expanding application versatility.
Category: Hex Nipple Connectors, Brand: AIRTAC, Series: APH
Installation protocol:
Use 8mm combination wrench for installation. Apply 0.8-1.2N·m torque
with thread sealant (PTFE tape recommended). Perform pressure test
at 1.25×system pressure after installation.
2. Superior flow performance achieving equivalent flow capacity to tubing inner diameter;
3. Tool-free tubing insertion/extraction with secure, durable, and leak-proof connections;
4. Threads pre-coated with sealant; M5 metric threads integrate sealing washers for leak-resistant threaded joints;
5. Nickel-plated brass body ensures corrosion resistance and contamination prevention, expanding application versatility.
Category: Hex Nipple Connectors, Brand: AIRTAC, Series: APH
AirTAC APH Series Hexagon Connector APH4-01 Technical Details
- Model: APH4-01 (ISO 15407 standard)
- Thread specification: M5×0.8 internal thread
- Material: Stainless steel 303 (corrosion-resistant)
- Surface treatment: Electropolished finish
- Hex size: 8mm AF (across flats)
- Max working pressure: 1.5 MPa (217 psi)
- Burst pressure: ≥4.5 MPa
- Temperature range: -20℃ to 150℃
- Sealing type: Metal-to-metal contact (no O-ring required)
- Weight: 12g ±0.5g
- Dimensions: 20mm(L) × 12mm(W) × 12mm(H)
- Thread engagement: 4 full turns minimum
- Vibration resistance: 10-2000Hz, 20G acceleration
Precision-machined hex fitting with full-flow design for minimal pressure drop. Features 360° rotatable connection interface and anti-vibration locking structure. Compatible with PEEK/Nylon tubing (OD 4mm). Meets ISO 14001 environmental standards.
Implementation Scenarios:
- High-cycle pneumatic tool connections
- Vacuum system manifold assemblies
- Robotic arm end effector plumbing
- Semiconductor equipment gas lines
- Hydraulic test bench instrumentation
Installation protocol:
Use 8mm combination wrench for installation. Apply 0.8-1.2N·m torque
with thread sealant (PTFE tape recommended). Perform pressure test
at 1.25×system pressure after installation.
Matched Components:
- AirTAC PIS series push-to-connect fittings
- ISO 1179-1 adapters
- DIN 2353 metric tube fittings
| Property | Property Value |
|---|---|
| sku | APH4-01 |
