Airtac APH Hex Head Connector APH4-02
2. Superior flow performance achieving equivalent flow capacity to tubing inner diameter;
3. Tool-free tubing insertion/extraction with secure, durable, and leak-proof connections;
4. Threads pre-coated with sealant; M5 metric threads integrate sealing washers for leak-resistant threaded joints;
5. Nickel-plated brass body ensures corrosion resistance and contamination prevention, expanding application versatility.
Category: Hex Nipple Connectors, Brand: AIRTAC, Series: APH
AirTAC APH4-02 Hexagon Threaded Connector Technical Details
- Model: APH4-02
- Type: Male hexagon threaded connector (straight)
- Thread standard: Metric (M5×0.8)
- Material: Stainless steel 303 with nickel plating
- Port size: 4mm nominal bore
- Max working pressure: 1.0 MPa (10 bar)
- Proof pressure: 1.5 MPa
- Burst pressure: 3.0 MPa
- Temperature range: -20℃ to 80℃
- Surface hardness: HV 200-250
- Weight: 14.2±0.5g
- Dimensions: 19.5mm(L) × 10mm(W) × 10mm(H)
- Hexagon size: 8mm AF
- Seal material: NBR (Nitrile) O-ring
- Corrosion resistance: 96hr salt spray test passed
Precision-machined pneumatic connector featuring anti-vibration grooves and dual sealing surfaces. The hexagonal body design allows tool-assisted tightening with 360° installation flexibility. Electroless nickel plating ensures corrosion resistance in humid environments while maintaining electrical conductivity for grounding applications.
- Pneumatic cylinder port connections
- Modular assembly in FRL (Filter-Regulator-Lubricator) units
- High-vibration environments like CNC machinery
- Plastic injection molding air lines
- Food processing equipment (FDA-compliant grease used)
Installation protocol:
Apply 2-3 wraps of PTFE tape clockwise on male threads.
Tighten to 1.2-1.5N·m torque using 8mm wrench.
Avoid overtightening to prevent port deformation.
Pressure test recommended after installation.
| Property | Property Value |
|---|---|
| sku | APH4-02 |
