Airtac APH Hex Head Connector APH6-03
$4.87
Regular price
$12.37
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APH6-03
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Available in multiple models and specifications, widely applicable in various pneumatic systems;
2. Superior flow performance achieving equivalent flow capacity to tubing inner diameter;
3. Tool-free tubing insertion/extraction with secure, durable, and leak-proof connections;
4. Threads pre-coated with sealant; M5 metric threads integrate sealing washers for leak-resistant threaded joints;
5. Nickel-plated brass body ensures corrosion resistance and contamination prevention, expanding application versatility.
Category: Hex Nipple Connectors, Brand: AIRTAC, Series: APH
Installation protocol:
Apply thread sealant to male threads only (Loctite 545 recommended).
Tighten to 1.2-1.5N·m torque using 8mm wrench. Avoid overtightening
which may deform O-ring groove. Perform pressure test at 1.5×
working pressure after installation.
2. Superior flow performance achieving equivalent flow capacity to tubing inner diameter;
3. Tool-free tubing insertion/extraction with secure, durable, and leak-proof connections;
4. Threads pre-coated with sealant; M5 metric threads integrate sealing washers for leak-resistant threaded joints;
5. Nickel-plated brass body ensures corrosion resistance and contamination prevention, expanding application versatility.
Category: Hex Nipple Connectors, Brand: AIRTAC, Series: APH
AirTAC APH Hexagon Connector APH6-03 Technical Specifications
- Model: APH6-03
- Thread type: M5×0.8 external hexagon
- Material: Stainless steel 303 (corrosion-resistant)
- Surface treatment: Electropolished finish
- Max working pressure: 1.0 MPa (10 bar)
- Temperature range: -20℃ to 150℃
- Seal type: Integrated NBR O-ring (replaceable)
- Hexagon size: 8mm across flats
- Thread length: 9±0.5mm
- Weight: 48±2g
- Dimensions: 30mm(L) × 12mm(W) × 14mm(H)
- Vibration resistance: ≤10Hz @ 2mm amplitude
- Certification: RoHS compliant
Precision-machined pneumatic connector featuring laser-etched thread specifications for visual verification. The chamfered entry design prevents O-ring damage during installation. Rated for 500,000+ connection cycles with <2% compression set on seals.
Ideal Applications:
- Modular pneumatic circuit assembly
- Robotic end-effector tooling
- CNC machine lubrication lines
- High-cycle automation fixtures
- Vacuum system port connections
Installation protocol:
Apply thread sealant to male threads only (Loctite 545 recommended).
Tighten to 1.2-1.5N·m torque using 8mm wrench. Avoid overtightening
which may deform O-ring groove. Perform pressure test at 1.5×
working pressure after installation.
| Property | Property Value |
|---|---|
| sku | APH6-03 |
