Airtac APH Hex Head Connector APH6-04
2. Superior flow performance achieving equivalent flow capacity to tubing inner diameter;
3. Tool-free tubing insertion/extraction with secure, durable, and leak-proof connections;
4. Threads pre-coated with sealant; M5 metric threads integrate sealing washers for leak-resistant threaded joints;
5. Nickel-plated brass body ensures corrosion resistance and contamination prevention, expanding application versatility.
Category: Hex Nipple Connectors, Brand: AIRTAC, Series: APH
AirTAC APH Hexagon Connector APH6-04 Technical Details
- Model: APH6-04 (Hexagon Straight Thread Connector)
- Thread type: M5×0.8 external thread (BSPP/PG optional)
- Seal configuration: Metal-to-metal sealing with O-ring backup
- Material: Nickel-plated brass body (C3604)
- Seal material: NBR (Nitrile) O-ring
- Pressure rating: 0.5-1.0 MPa (72.5-145 psi)
- Temperature range: -20℃ to 80℃ (continuous operation)
- Surface treatment: Electroless nickel plating (8-12μm)
- Hex size: 10mm AF (across flats)
- Weight: 8.2g ±0.3g
- Dimensions: 25mm(L) × 10mm(W) × 12mm(H)
- Thread engagement: Minimum 3 full turns required
- Vibration resistance: ≤15Hz frequency, 1.5mm amplitude
High-density forged connector with dual sealing mechanism, featuring a 360° rotatable hex body for tool access in confined spaces. The chromium-free plating ensures environmental compliance, while the tapered thread design prevents loosening under vibration. Compatible with pneumatic tubing OD 6mm (1/4").
- Manifold block port conversions in modular pneumatic systems
- Sensor/valve mounting interfaces on automated assembly lines
- Compressed air distribution in CNC machine tool cabinets
- Vacuum circuit connections for material handling robots
- Hydraulic test bench instrumentation ports (low-pressure)
Installation protocol:
Apply 2-3 drops of pneumatic sealant (Loctite 577 equivalent) on male threads before assembly.
Tighten with 10mm combination wrench using 1.2-1.5N·m torque. Avoid overtightening - maximum
180° rotation after hand-tight position.
| Property | Property Value |
|---|---|
| sku | APH6-04 |
