Airtac APH Hex Head Connector APH8-02
2. Superior flow performance achieving equivalent flow capacity to tubing inner diameter;
3. Tool-free tubing insertion/extraction with secure, durable, and leak-proof connections;
4. Threads pre-coated with sealant; M5 metric threads integrate sealing washers for leak-resistant threaded joints;
5. Nickel-plated brass body ensures corrosion resistance and contamination prevention, expanding application versatility.
Category: Hex Nipple Connectors, Brand: AIRTAC, Series: APH
AirTAC APH8-02 Hexagon Threaded Connector Technical Details
- Model: APH8-02
- Thread type: M5×0.8 external hexagon
- Material: C3604 free-cutting brass (lead-free compliant)
- Surface treatment: Electroless nickel plating (5-8μm)
- Pressure rating: 0.05–1.0 MPa
- Temperature range: -20℃ to 120℃ (continuous use)
- Proof pressure: 1.5 MPa
- Burst pressure: 3.0 MPa
- Hexagon size: 8mm AF (across flats)
- Thread engagement length: 7.5±0.3mm
- Seal type: Metal-to-metal sealing (no O-ring required)
- Weight: 4.2±0.3 grams
- Dimensions: 16mm(L) × 8mm(W) × 8mm(H)
- Torque specification: 0.7–1.2 N·m (installation)
- Compliance: RoHS 2.0, REACH SVHC
Precision-machined brass connector featuring cold-forged hex body for superior torque resistance. The rolled thread design ensures smooth engagement while maintaining 100% air-tightness without auxiliary sealants. Nickel plating provides corrosion protection against moisture and mild chemicals.
- Modular pneumatic circuit assembly in factory automation
- Sensor mounting brackets requiring vibration resistance
- Compact fluid control systems with space constraints
- Vacuum line connections in semiconductor equipment
- Robotic end-effector pneumatic interfaces
Installation guide:
Apply 1.5-2 wraps of PTFE tape clockwise on male threads.
Use 8mm combination wrench for installation - avoid adjustable wrenches
to prevent hex deformation. Maximum re-use cycles: 5 times.
| Property | Property Value |
|---|---|
| sku | APH8-02 |
