Airtac APKD Threaded 5-Way Fitting APKD10-8-03
$5.91
Regular price
$13.41
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APKD10-8-03
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Available in multiple models/specifications, widely applicable to various pneumatic systems;
2、Superior flow performance with a capacity matching the inner diameter of pneumatic tubing;
3、Tool-free tube insertion/extraction ensures quick and secure connections, offering reliable and long-lasting tubing integration;
4、Sealant-coated threads and M5 metric threads with integrated sealing washers guarantee leak-proof threaded connections;
5、Nickel-plated brass body provides enhanced corrosion and contamination resistance for extended application versatility.
Category: Threaded 5-Way Fitting , Brand: Airtac , Series: PKD
Installation guidelines:
Apply 2-3 wraps of PTFE tape on male threads. Tighten to 1.2-1.5 N·m torque using
a 10mm crowfoot wrench. Ensure tube inserts are fully seated before connection.
Perform pressure test at 1.8 MPa for 5 minutes during commissioning.
2、Superior flow performance with a capacity matching the inner diameter of pneumatic tubing;
3、Tool-free tube insertion/extraction ensures quick and secure connections, offering reliable and long-lasting tubing integration;
4、Sealant-coated threads and M5 metric threads with integrated sealing washers guarantee leak-proof threaded connections;
5、Nickel-plated brass body provides enhanced corrosion and contamination resistance for extended application versatility.
Category: Threaded 5-Way Fitting , Brand: Airtac , Series: PKD
AirTAC APKD Threaded Five-Way Union APKD10-8-03 Technical Details
- Model: APKD10-8-03
- Type: Brass five-way threaded union with locking nut
- Material: Lead-free brass (CuZn39Pb3) with nickel plating
- Thread specifications: M5×0.8 (male thread) / PT1/8 (female thread)
- Port configuration: 1 input, 4 output ports (90° radial distribution)
- Max working pressure: 1.5 MPa (217 psi)
- Pressure range: 0.05-1.5 MPa
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Tube compatibility: 4mm OD polyurethane/nylon tubing
- Seal material: NBR (Nitrile) O-rings
- Weight: 24.5g ±0.5g
- Dimensions: 38mm(L) × 22mm(W) × 22mm(H)
- Surface roughness: Ra ≤1.6μm
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Protection rating: IP40 (dust protected)
Precision-machined pneumatic distribution block designed for compact manifold applications. Features corrosion-resistant nickel plating and 4-way symmetrical flow paths with positive-lock threaded connections. Includes integrated strain relief grooves for secure tubing retention.
Typical Applications:
- Multi-actuator control in robotic gripper systems
- Pneumatic circuit branching for assembly line equipment
- Air distribution in modular pneumatic manifolds
- Medical device pneumatic control clusters
- Educational pneumatic training kits
Installation guidelines:
Apply 2-3 wraps of PTFE tape on male threads. Tighten to 1.2-1.5 N·m torque using
a 10mm crowfoot wrench. Ensure tube inserts are fully seated before connection.
Perform pressure test at 1.8 MPa for 5 minutes during commissioning.
Compatible Components:
- AirTAC SDA series compact cylinders
- 3V1 series solenoid valves
- APEM6-M5 pressure sensors
- 4mm push-to-connect fittings (APQC4-01)
