Airtac APL L-type Elbow Fitting APL10-01
2、Superior flow performance achieves throughput equivalent to the inner diameter of connected tubing;
3、Features plug-and-play convenience with secure and durable tubing connections;
4、Threads pre-coated with sealing compound, M5 metric threads incorporate sealing gasket for leak-free threaded connections;
5、Nickel-plated brass body provides enhanced resistance to corrosion and contamination, expanding application scope.
Category: L-Type Elbow Fitting , Brand: AIRTAC , Series: APL
AirTAC APL Series L-Type Elbow Fitting APL10-01 Technical Details
- Model: APL10-01 (L-Type 90° Elbow)
- Thread Standard: Metric/PT/NPT optional
- Port Size: PT1/8 (R1/8, G1/8, NPT1/8 compatible)
- Material: Brass with nickel plating (stainless steel variant available)
- Surface Treatment: Electroplated corrosion protection
- Max Working Pressure: 1.0 MPa (145 psi)
- Proof Pressure: 1.5 MPa
- Burst Pressure: 3.0 MPa
- Operating Temp Range: -20℃ to 80℃ (-4°F to 176°F)
- Seal Material: NBR (Nitrile) standard, FKM (Viton) optional
- Weight: 14.5g ±0.3g
- Dimensions: 24.5mm(L) × 18.2mm(W) × 18.2mm(H)
- Flow Coefficient (Cv): 0.12
- Vibration Resistance: 10-55Hz, 1.5mm amplitude
- Certifications: RoHS compliant, ISO 9001 manufacturing
Precision-engineered L-shaped pneumatic connector featuring dual-port sealing technology with 5-stage surface treatment for leak-proof performance. The 90° angled design enables compact piping layouts while maintaining laminar airflow (turbulence reduction <15%). Internal polishing achieves Ra0.8μm surface roughness.
- Dense pneumatic manifolds requiring directional changes
- Robotic arm end-effector tooling connections
- CNC machine tool pneumatic circuit branching
- Vacuum system instrumentation lines
- Medical gas delivery systems (oxygen/nitrogen)
Mounting protocol:
Apply 2-3 wraps of PTFE tape clockwise on male threads.
Tighten to 12-15 N·m torque using crowfoot wrench.
Avoid overtightening - maximum rotation angle after hand-tight: 1.5 turns.
| Property | Property Value |
|---|---|
| sku | APL10-01 |
