Airtac APL L-type Elbow Fitting APL10-02
2、Superior flow performance achieves throughput equivalent to the inner diameter of connected tubing;
3、Features plug-and-play convenience with secure and durable tubing connections;
4、Threads pre-coated with sealing compound, M5 metric threads incorporate sealing gasket for leak-free threaded connections;
5、Nickel-plated brass body provides enhanced resistance to corrosion and contamination, expanding application scope.
Category: L-Type Elbow Fitting , Brand: AIRTAC , Series: APL
AirTAC APL Series L-Type Elbow Fitting APL10-02 Technical Details
- Model: APL10-02 (L-type 90° elbow)
- Thread specification: G1/8 (BSPP) female threads both ends
- Material: Nickel-plated brass (base), CRN rubber seals
- Max working pressure: 1.0 MPa (145 psi)
- Proof pressure: 1.5 MPa
- Temperature range: -5℃ to 80℃ (non-condensing environment)
- Flow coefficient (Cv): 0.45
- Weight: 28g ±2g (including packaging)
- Dimensions: 21mm(A) × 21mm(B) × 18mm(C) (L-shape profile)
- Surface roughness: Ra ≤3.2μm (internal bore)
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Certification: RoHS compliant
Precision-engineered L-shaped pneumatic connector featuring dual-axis 90° deflection capability. The through-hole design maintains 2.5mm minimum inner diameter for optimized airflow, with triple-layer nickel plating providing 480hr salt spray resistance. Includes integrated O-ring groove for positive seal retention.
- Space-constrained pneumatic circuit routing in robotics
- Tooling fixture air line connections
- Medical device pneumatic manifolds requiring compact bends
- Precision instrument air bleed systems
- Packaging machine rotary joint interfaces
Mounting guidance:
Apply 2-3 wraps of PTFE tape on male threads (clockwise winding).
Tighten to 12-15N·m torque using 17mm crowfoot wrench. Avoid aligning
bending moment with primary airflow direction during assembly.
| Property | Property Value |
|---|---|
| sku | APL10-02 |
