Airtac APL L-type Elbow Fitting APL10-03
2、Superior flow performance achieves throughput equivalent to the inner diameter of connected tubing;
3、Features plug-and-play convenience with secure and durable tubing connections;
4、Threads pre-coated with sealing compound, M5 metric threads incorporate sealing gasket for leak-free threaded connections;
5、Nickel-plated brass body provides enhanced resistance to corrosion and contamination, expanding application scope.
Category: L-Type Elbow Fitting , Brand: AIRTAC , Series: APL
AirTAC APL Series L-Type Elbow Fitting APL10-03 Technical Details
- Model: APL10-03 (L-type 90° elbow)
- Thread Standard: Metric (M5×0.8 female thread)
- Material: Nickel-plated brass (C3604)
- Max Working Pressure: 1.5 MPa (217 psi)
- Temperature Range: -5℃ to 80℃ (with NBR seals)
- Seal Material: NBR (Standard) / Optional FKM
- Surface Treatment: Electroless nickel plating (8-12μm)
- Proof Pressure: 2.25 MPa
- Burst Pressure: ≥3 MPa
- Weight: 18.5±0.5g
- Dimensions: 23mm(L) × 16mm(W) × 21mm(H)
- Flow Coefficient (Cv): 0.15
- Vibration Resistance: 10-55Hz, 1.5mm amplitude
Precision-machined L-shaped pneumatic connector designed for 90° tubing redirection in compact spaces. Features triple-layer nickel plating for corrosion resistance and leak-free NBR seals. Compatible with PU/NYLON tubing (ID 3.2mm). Includes integrated O-ring groove for positive sealing.
- Robotic arm pneumatic circuit routing
- CNC machine tool air supply manifolds
- Packaging equipment sensor air lines
- Medical device pneumatic control systems
- Semiconductor wafer handling vacuum circuits
Mounting Guidance:
Apply 2-3 wraps of PTFE tape on male threads (Do NOT over-tighten - recommended torque 1.2-1.5N·m).
For vertical downward installations, use thread locker to prevent vibration loosening.
| Property | Property Value |
|---|---|
| sku | APL10-03 |
