Airtac APL L-type Elbow Fitting APL10-04
2、Superior flow performance achieves throughput equivalent to the inner diameter of connected tubing;
3、Features plug-and-play convenience with secure and durable tubing connections;
4、Threads pre-coated with sealing compound, M5 metric threads incorporate sealing gasket for leak-free threaded connections;
5、Nickel-plated brass body provides enhanced resistance to corrosion and contamination, expanding application scope.
Category: L-Type Elbow Fitting , Brand: AIRTAC , Series: APL
AirTAC APL L-Shaped Elbow Fitting APL10-04 Technical Details
- Model: APL10-04 (L-type 90° elbow)
- Thread standard: Metric (M5×0.8) & PT1/8" dual markings
- Material: CNC-machined stainless steel SS304
- Seal type: Embedded NBR O-ring (oil-resistant)
- Max working pressure: 1.5 MPa (217 psi)
- Temperature range: -20℃ to 120℃
- Surface treatment: Electropolished finish (Ra≤0.8μm)
- Flow coefficient: Cv≈0.12
- Weight: 12g ±0.5g
- Dimensions: 18mm(L) × 16mm(W) × 21mm(H)
- Torque resistance: ≤2.5N·m installation torque
Precision-machined L-shaped pneumatic connector featuring dual-thread compatibility and anti-vibration design. The 90° angled flow path optimizes compact installations while maintaining laminar airflow. Chrome-free passivation treatment meets RoHS compliance.
- Pneumatic valve manifold block interconnections
- Robotic end-effector tooling air supply lines
- Medical device pneumatic circuit routing
- CNC machine tool cooling air distribution
- Semiconductor fab equipment plumbing
Maintenance protocol:
Apply Loctite 577 thread sealant (not included) for high-vibration environments.
Maximum 1/2 rotation past finger-tight during assembly to prevent O-ring deformation.
* Compatible with 4mm OD polyurethane tubing (max 6mm bend radius). Requires periodic inspection every 2,000 operating hours in continuous duty applications.
| Property | Property Value |
|---|---|
| sku | APL10-04 |
