Airtac APL L-type Elbow Fitting APL10-M10
$3.84
Regular price
$11.34
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APL10-M10
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Available in multiple models and specifications, widely applicable to various pneumatic systems;
2、Superior flow performance achieves throughput equivalent to the inner diameter of connected tubing;
3、Features plug-and-play convenience with secure and durable tubing connections;
4、Threads pre-coated with sealing compound, M5 metric threads incorporate sealing gasket for leak-free threaded connections;
5、Nickel-plated brass body provides enhanced resistance to corrosion and contamination, expanding application scope.
Category: L-Type Elbow Fitting , Brand: AIRTAC , Series: APL
Installation guidance:
Apply 1.2-1.8 N·m torque during assembly. Use thread sealant only on male threads,
avoiding contact with O-ring surfaces. Maximum recommended re-tightening cycles: 3 times.
2、Superior flow performance achieves throughput equivalent to the inner diameter of connected tubing;
3、Features plug-and-play convenience with secure and durable tubing connections;
4、Threads pre-coated with sealing compound, M5 metric threads incorporate sealing gasket for leak-free threaded connections;
5、Nickel-plated brass body provides enhanced resistance to corrosion and contamination, expanding application scope.
Category: L-Type Elbow Fitting , Brand: AIRTAC , Series: APL
AirTAC APL Series L-Type Elbow Fitting APL10-M10 Technical Details
- Model: APL10-M10
- Type: 90° L-shaped pneumatic elbow connector
- Thread specification: M10×1.0 (male thread)
- Material: Nickel-plated brass (C3604)
- Seal material: HNBR (Hydrogenated Nitrile) O-ring
- Max working pressure: 1.5 MPa (217 psi)
- Temperature range: -20℃ to 150℃
- Surface hardness: HV 0.3/5 ≥160 (nickel coating)
- Weight: 18.5±0.5g
- Dimensions: 23mm(L) × 18mm(W) × 18mm(H)
- Thread engagement depth: 8mm
- Flow coefficient (Cv): 0.38
- Vibration resistance: 10-2000Hz, 1.5mm amplitude
Precision-machined L-shaped fitting with triple-layer nickel plating for enhanced corrosion resistance in humid environments. Features anti-vibration grooves and 360° rotatable design for flexible piping alignment. Compatible with ISO 1179-2 standard pneumatic systems.
Typical Applications:
- Compact pneumatic circuit routing in robotic arms
- Space-constrained industrial automation equipment
- Medical device pneumatic connections
- High-cycle production line tooling
- Mobile hydraulic/pneumatic hybrid systems
Installation guidance:
Apply 1.2-1.8 N·m torque during assembly. Use thread sealant only on male threads,
avoiding contact with O-ring surfaces. Maximum recommended re-tightening cycles: 3 times.
| Property | Property Value |
|---|---|
| sku | APL10-M10 |
