Airtac APL L-type Elbow Fitting APL10-M12
$3.84
Regular price
$11.34
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APL10-M12
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Available in multiple models and specifications, widely applicable to various pneumatic systems;
2、Superior flow performance achieves throughput equivalent to the inner diameter of connected tubing;
3、Features plug-and-play convenience with secure and durable tubing connections;
4、Threads pre-coated with sealing compound, M5 metric threads incorporate sealing gasket for leak-free threaded connections;
5、Nickel-plated brass body provides enhanced resistance to corrosion and contamination, expanding application scope.
Category: L-Type Elbow Fitting , Brand: AIRTAC , Series: APL
Installation protocol:
Apply 2-3 wraps of PTFE tape clockwise on male threads.
Use torque wrench for final tightening - over-tightening may collapse
O-ring groove. Perform pressure test at 1.25× working pressure after installation.
2、Superior flow performance achieves throughput equivalent to the inner diameter of connected tubing;
3、Features plug-and-play convenience with secure and durable tubing connections;
4、Threads pre-coated with sealing compound, M5 metric threads incorporate sealing gasket for leak-free threaded connections;
5、Nickel-plated brass body provides enhanced resistance to corrosion and contamination, expanding application scope.
Category: L-Type Elbow Fitting , Brand: AIRTAC , Series: APL
AirTAC APL Series L-Elbow Fitting APL10-M12 Technical Details
- Model: APL10-M12
- Type: 90° male-threaded L-shaped pneumatic connector
- Thread specification: M12×1.0 (external thread)
- Material: Brass (CuZn39Pb3) with nickel-plated surface
- Seal type: Integrated O-ring (NBR standard/FKM optional)
- Pressure range: 0-1.0 MPa (145 psi)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Surface roughness: Ra ≤1.6μm
- Tightening torque: 3.5-4.5 N·m
- Weight: 22.5±0.8g
- Dimensions: 21.5mm(L) × 18mm(W) × 18mm(H)
- Thread engagement depth: 8.5mm
- Flow rate: 450 NL/min (at 0.5MPa)
- Vibration resistance: 10-55Hz, 1.5mm amplitude
Precision-machined L-shaped pneumatic fitting designed for high-density piping layouts. Features anti-vibration grooves and leak-proof tapered seat design. The nickel plating provides corrosion resistance in humid environments (salt spray test passed 96hrs).
Typical Applications:
- Robotic arm pneumatic circuit connections
- CNC machine tool air nozzle assemblies
- Semiconductor wafer handling equipment
- Food-grade pneumatic systems (FKM seal version)
- High-cycle automation test rigs
Installation protocol:
Apply 2-3 wraps of PTFE tape clockwise on male threads.
Use torque wrench for final tightening - over-tightening may collapse
O-ring groove. Perform pressure test at 1.25× working pressure after installation.
| Property | Property Value |
|---|---|
| sku | APL10-M12 |
