Airtac APL L-type Elbow Fitting APL10-M16
2、Superior flow performance achieves throughput equivalent to the inner diameter of connected tubing;
3、Features plug-and-play convenience with secure and durable tubing connections;
4、Threads pre-coated with sealing compound, M5 metric threads incorporate sealing gasket for leak-free threaded connections;
5、Nickel-plated brass body provides enhanced resistance to corrosion and contamination, expanding application scope.
Category: L-Type Elbow Fitting , Brand: AIRTAC , Series: APL
AirTAC APL L-Type Elbow Fitting APL10-M16 Technical Details
- Model: APL10-M16
- Type: 90° L-shaped pneumatic connector
- Thread specification: M16×1.5 (external thread both ends)
- Material: Nickel-plated brass body
- Seal material: NBR seals
- Max working pressure: 1.5 MPa (217 psi)
- Temperature range: -5℃ to 80℃ (with NBR seals)
- Proof pressure: 2.25 MPa
- Burst pressure: ≥3 MPa
- Surface treatment: Electroplated zinc with chromate finish
- Weight: 48±2 grams
- Dimensions: 32mm (L) × 26mm (W) × 26mm (H)
- Flow characteristics: Cv=0.15
- Vibration resistance: 10-55Hz, 1.5mm amplitude
Precision-machined L-shaped pneumatic fitting designed for high-density piping layouts. Features dual O-ring seals for leak-free connections and hexagonal wrench flats for tool tightening. Nickel plating provides corrosion resistance in humid environments. Compatible with ISO 1179-2 standard ports.
- Space-constrained robotic arm end effectors
- Modular pneumatic manifolds requiring right-angle turns
- CNC machine tool coolant control systems
- Packaging equipment air circuit distribution
- Laboratory automation gas sampling lines
Installation protocol:
Apply 2-3 wraps of PTFE tape on male threads (clockwise winding).
Tighten to 14-16 N·m torque using 22mm wrench.
Perform pressure test at 1.1× system pressure after installation.
| Property | Property Value |
|---|---|
| sku | APL10-M16 |
