Airtac APL L-type Elbow Fitting APL10-M20
2、Superior flow performance achieves throughput equivalent to the inner diameter of connected tubing;
3、Features plug-and-play convenience with secure and durable tubing connections;
4、Threads pre-coated with sealing compound, M5 metric threads incorporate sealing gasket for leak-free threaded connections;
5、Nickel-plated brass body provides enhanced resistance to corrosion and contamination, expanding application scope.
Category: L-Type Elbow Fitting , Brand: AIRTAC , Series: APL
AirTAC APL Series L-Shaped Elbow Fitting APL10-M20 Technical Details
- Model: APL10-M20
- Type: L-shaped pneumatic elbow connector
- Material: Nickel-plated brass body
- Seal material: NBR (Nitrile) rubber
- Thread specification: M20×1.5 male thread (both ends)
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃
- Burst pressure: ≥3.0 MPa
- Flow coefficient (Cv): 0.65
- Weight: 148g ±2g
- Dimensions: 32mm(L) × 24mm(W) × 35mm(H)
- Surface treatment: Electroless nickel plating (5-8μm)
- Vibration resistance: 10–55Hz, 1.5mm amplitude
90-degree angled pneumatic fitting engineered for high-density piping layouts. Features triple-layer nickel plating for enhanced corrosion resistance in humid environments. The internal flow path is precision-polished to minimize pressure drop (ΔP ≤0.02MPa @ 0.5MPa). Compatible with ISO 1179-1 standard connectors.
- Compact pneumatic valve island connections
- Robotic end-effector tooling air supply
- CNC machine tool pneumatic circuit branching
- Packaging line actuator manifolds
- Semiconductor equipment gas distribution
Installation protocol:
Apply 2.5–3 wraps of PTFE tape on male threads (clockwise winding).
Tighten to 25–30 N·m torque using crowfoot wrench. Avoid overtightening
which may deform NBR seals. Perform pressure test at 1.5× system pressure
after installation.
