Airtac APL L-type Elbow Fitting APL12-02
2、Superior flow performance achieves throughput equivalent to the inner diameter of connected tubing;
3、Features plug-and-play convenience with secure and durable tubing connections;
4、Threads pre-coated with sealing compound, M5 metric threads incorporate sealing gasket for leak-free threaded connections;
5、Nickel-plated brass body provides enhanced resistance to corrosion and contamination, expanding application scope.
Category: L-Type Elbow Fitting , Brand: AIRTAC , Series: APL
AirTAC APL L-Type Elbow Fitting APL12-02 Technical Details
- Model: APL12-02
- Type: 90° L-shaped pneumatic elbow connector
- Material: Brass (Nickel-plated) body with corrosion-resistant coating
- Port size: 1/8" BSPP (G1/8)
- Thread specification: ISO 228-1 compliant
- Max working pressure: 1.5 MPa (217 psi)
- Burst pressure: ≥4.5 MPa (653 psi)
- Temperature range: -5℃ to 80℃ (23°F to 176°F)
- Seal material: NBR (Nitrile) O-rings (Optional FKM/Viton available)
- Surface roughness: Ra ≤3.2μm
- Weight: 12.5g ±0.3g
- Dimensions: 22mm(L) × 18mm(W) × 18mm(H)
- Torque resistance: ≤2.5N·m installation torque
- Leakage rate: ≤0.1 NL/min @ 0.5MPa
Precision-machined L-shaped connector enabling 90° pneumatic line redirection in confined spaces. Features triple-layer nickel plating for enhanced corrosion resistance and smooth airflow. The compact design minimizes pressure drop (ΔP ≤0.02MPa @ 0.5MPa) while maintaining structural integrity under vibration.
- Pneumatic valve manifold interconnections
- Robotic arm tooling air supply lines
- CNC machine tool pneumatic circuits
- Packaging equipment air distribution
- Semiconductor manufacturing gas lines
- Medical device pneumatic systems
Installation guidelines:
Apply PTFE tape clockwise on male threads (2.5 wraps recommended).
Hand-tighten plus 1/4 turn with wrench. Avoid overtightening -
maximum torque 2.2N·m. Inspect O-rings quarterly in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | APL12-02 |
