Airtac APL L-type Elbow Fitting APL12-03
2、Superior flow performance achieves throughput equivalent to the inner diameter of connected tubing;
3、Features plug-and-play convenience with secure and durable tubing connections;
4、Threads pre-coated with sealing compound, M5 metric threads incorporate sealing gasket for leak-free threaded connections;
5、Nickel-plated brass body provides enhanced resistance to corrosion and contamination, expanding application scope.
Category: L-Type Elbow Fitting , Brand: AIRTAC , Series: APL
AirTAC APL L-Type Elbow Fitting APL12-03 Technical Details
- Model: APL12-03 (L-type 90° elbow)
- Thread standard: Metric/PT/NPT optional
- Port size: 1/8" BSPP (G1/8) equivalent
- Material: Nickel-plated brass core + PBT resin body
- Max working pressure: 1.5 MPa (217 psi)
- Temperature range: -5℃ to 80℃ (non-freezing)
- Seal type: Integrated NBR O-ring
- Weight: 18.5±0.3g
- Dimensions: 22.5mm(L) × 16mm(W) × 28mm(H)
- Surface resistance: 10^9 Ω (anti-static)
- Vibration resistance: 10-55Hz @1.5mm amplitude
Precision-machined L-shaped pneumatic connector with 90° flow path optimization, featuring dual-material construction for corrosion resistance and structural rigidity. The stepped thread design ensures leak-free connections up to 1.5MPa. Compatible with φ4/6/8mm push-in tubing (requires matching insert sleeves).
- Pneumatic cylinder port redirection in robotic arms
- Compact valve manifolds for packaging machinery
- Air brake line routing in material handling systems
- Medical device pneumatic circuit optimization
- 3D printer air-assisted cooling systems
Installation protocol:
Hand-tighten plus 1/4 turn with wrench (max 3.5N·m torque).
Apply thread sealant only on male threads. Avoid overtightening
plastic body - use counter-holding tool during assembly.
| Property | Property Value |
|---|---|
| sku | APL12-03 |
