Airtac APL L-type Elbow Fitting APL12-04
2、Superior flow performance achieves throughput equivalent to the inner diameter of connected tubing;
3、Features plug-and-play convenience with secure and durable tubing connections;
4、Threads pre-coated with sealing compound, M5 metric threads incorporate sealing gasket for leak-free threaded connections;
5、Nickel-plated brass body provides enhanced resistance to corrosion and contamination, expanding application scope.
Category: L-Type Elbow Fitting , Brand: AIRTAC , Series: APL
AirTAC APL L-Type Elbow Fitting APL12-04 Technical Details
- Model: APL12-04 (L-Type 90° Elbow)
- Thread standard: BSPP (G) / NPT optional
- Port size: 1/4" (12mm nominal)
- Through-hole diameter: 4mm
- Material: Brass (CuZn39Pb3) with nickel plating
- Surface hardness: ≥HV200
- Max working pressure: 1.0 MPa (145 psi)
- Temperature range: -5℃ to 60℃
- Seal material: NBR (Nitrile O-ring)
- Torque resistance: ≤1.5 N·m during installation
- Weight: 18.5g ±0.3g
- Dimensions: 24mm (L) × 24mm (W) × 21mm (H)
- Compliance: RoHS 2011/65/EU
Precision-machined L-shaped pneumatic connector featuring a 90° flow path for space-constrained installations. The electroless nickel coating provides corrosion resistance (48h salt spray test passed) while maintaining smooth airflow. Designed with a 4mm unrestricted bore to minimize pressure drop (ΔP ≤0.02MPa at 5L/min).
- Re-routing pneumatic lines in robotic gripper assemblies
- Compact valve manifolds in injection molding machines
- Tool-free maintenance connections for CNC equipment
- Vacuum system plumbing in semiconductor handling devices
- Modular pneumatic circuit prototyping
Installation protocol:
Apply 1.5-2 wraps of PTFE tape on male threads (do not over-tighten beyond 1.2 N·m).
For NPT versions, use liquid thread sealant. Avoid using in axial vibration environments exceeding 15g-force.
| Property | Property Value |
|---|---|
| sku | APL12-04 |
