Airtac APL L-type Elbow Fitting APL12-M12
2、Superior flow performance achieves throughput equivalent to the inner diameter of connected tubing;
3、Features plug-and-play convenience with secure and durable tubing connections;
4、Threads pre-coated with sealing compound, M5 metric threads incorporate sealing gasket for leak-free threaded connections;
5、Nickel-plated brass body provides enhanced resistance to corrosion and contamination, expanding application scope.
Category: L-Type Elbow Fitting , Brand: AIRTAC , Series: APL
AirTAC APL Series L-Shaped Elbow Connector APL12-M12 Technical Details
- Model: APL12-M12
- Type: Metric thread L-type pneumatic elbow
- Thread specification: M12×1.25 (male thread both ends)
- Material: Nickel-plated brass (C3604)
- Seal type: Integrated O-ring (NBR rubber)
- Operating pressure: 0.05-1.0 MPa
- Proof pressure: 1.5 MPa
- Temperature range: -5℃ to 80℃ (with NBR seals)
- Surface treatment: Electroless nickel plating (5-8μm)
- Weight: 28±2 grams
- Dimensions: 34mm(L) × 28mm(W) × 28mm(H)
- Flow coefficient (Cv): 0.15
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- IP rating: IP40 (dust protected)
Precision-machined L-shaped pneumatic connector featuring 90° flow direction change with minimal pressure drop. The compact nickel-plated brass construction ensures corrosion resistance in humid environments while maintaining structural integrity under vibration. Sealing surfaces are precision-lapped for bubble-tight connections when properly torqued.
- Space-constrained pneumatic manifolds in robotic end effectors
- Sensor mounting brackets requiring angled air supply
- Compact pneumatic circuit assemblies in packaging machinery
- Medical device pneumatic systems requiring hygienic metal fittings
- Mobile equipment with vibration-prone environments
Installation protocol:
Use 17mm open-end wrench for installation. Apply thread sealant (PTFE tape or liquid seal)
only on male threads. Recommended tightening torque: 12-15N·m. Perform pressure test at
1.2× working pressure after installation.
| Property | Property Value |
|---|---|
| sku | APL12-M12 |
