Airtac APL L-type Elbow Fitting APL12-M16
2、Superior flow performance achieves throughput equivalent to the inner diameter of connected tubing;
3、Features plug-and-play convenience with secure and durable tubing connections;
4、Threads pre-coated with sealing compound, M5 metric threads incorporate sealing gasket for leak-free threaded connections;
5、Nickel-plated brass body provides enhanced resistance to corrosion and contamination, expanding application scope.
Category: L-Type Elbow Fitting , Brand: AIRTAC , Series: APL
AirTAC APL L-Shaped Elbow Connector APL12-M16 Technical Details
- Model: APL12-M16
- Type: 90° L-shaped pneumatic elbow connector
- Thread specification: M16×1.5 (external thread both ends)
- Material: Brass with nickel plating (CuZn39Pb3)
- Seal material: NBR (Nitrile rubber) O-ring
- Max working pressure: 1.5 MPa (15 bar)
- Temperature range: -20℃ to 80℃
- Surface roughness: Ra ≤3.2μm
- Tightening torque: 25-30 N·m
- Weight: 48±2g
- Dimensions: 40mm(L) × 25mm(W) × 25mm(H)
- Flow coefficient (Cv): 2.8
- Vibration resistance: 10-2000Hz, 20m/s²
- Certification: RoHS compliant
Precision-machined L-shaped connector with dual-axis alignment capability, featuring corrosion-resistant nickel plating and anti-vibration thread design. The 8mm internal flow path minimizes pressure drop, while the 360° rotatable design allows flexible orientation adjustment during installation. Compatible with ISO 1179-2 standard ports.
- Pneumatic cylinder port redirection in robotic arms
- Compact piping layouts in packaging machinery
- Space-constrained industrial robot end effectors
- Modular pneumatic circuit connections
- CNC machine tool air supply line routing
Installation guidelines:
Apply PTFE tape or liquid sealant on male threads (do not exceed 3 wraps).
Use two wrenches to prevent rotation-induced stress - hold base fitting with 19mm wrench
while tightening with 22mm wrench. Perform pressure test at 1.75MPa after installation.
| Property | Property Value |
|---|---|
| sku | APL12-M16 |
