Airtac APL L-type Elbow Fitting APL12-M20
2、Superior flow performance achieves throughput equivalent to the inner diameter of connected tubing;
3、Features plug-and-play convenience with secure and durable tubing connections;
4、Threads pre-coated with sealing compound, M5 metric threads incorporate sealing gasket for leak-free threaded connections;
5、Nickel-plated brass body provides enhanced resistance to corrosion and contamination, expanding application scope.
Category: L-Type Elbow Fitting , Brand: AIRTAC , Series: APL
AirTAC APL Series L-Type Elbow Fitting APL12-M20 Technical Details
- Model: APL12-M20
- Type: 90° L-shaped pneumatic elbow connector
- Thread specification: M20×1.5 (male thread both ends)
- Material: Brass with nickel-plated surface
- Seal material: NBR (Nitrile rubber)
- Operating pressure: 0-1.5 MPa (217.5 PSI)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Surface hardness: ≥HV200
- Leakage rate: ≤0.1 NL/min under 0.5 MPa
- Weight: 52g ±2g
- Dimensions: 32mm(L) × 28mm(W) × 34mm(H)
- Torque resistance: ≤25 N·m
- Vibration resistance: 10-2000Hz, 15G acceleration
Precision-engineered L-shaped pneumatic fitting featuring dual-port 20mm metric threads with 1.5mm pitch. The compact nickel-plated brass construction provides corrosion resistance in humid environments while maintaining 500,000+ cycle durability. Internal flow-optimized design reduces turbulence (pressure drop <0.02MPa at 5m/s flow).
- Pneumatic cylinder port redirection in robotic arms
- Space-constrained pneumatic circuit layouts
- CNC machine tool air supply connections
- Packaging equipment air line management
- Compressed air instrument installations
Installation guidelines:
Apply 2-3 wraps of PTFE tape on male threads (do not over-tighten).
Maximum recommended torque 35 N·m. Avoid direct contact with hydraulic oils.
| Property | Property Value |
|---|---|
| sku | APL12-M20 |
