Airtac APL L-type Elbow Fitting APL14-02
$9.53
Regular price
$17.03
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APL14-02
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Available in multiple models and specifications, widely applicable to various pneumatic systems;
2、Superior flow performance achieves throughput equivalent to the inner diameter of connected tubing;
3、Features plug-and-play convenience with secure and durable tubing connections;
4、Threads pre-coated with sealing compound, M5 metric threads incorporate sealing gasket for leak-free threaded connections;
5、Nickel-plated brass body provides enhanced resistance to corrosion and contamination, expanding application scope.
Category: L-Type Elbow Fitting , Brand: AIRTAC , Series: APL
Installation guidance:
Apply thread sealant only on male threads (PTFE tape recommended).
Tightening torque should not exceed 0.25N·m. Rotate fittings by hand
for final 1/4 turn alignment without over-compression.
2、Superior flow performance achieves throughput equivalent to the inner diameter of connected tubing;
3、Features plug-and-play convenience with secure and durable tubing connections;
4、Threads pre-coated with sealing compound, M5 metric threads incorporate sealing gasket for leak-free threaded connections;
5、Nickel-plated brass body provides enhanced resistance to corrosion and contamination, expanding application scope.
Category: L-Type Elbow Fitting , Brand: AIRTAC , Series: APL
AirTAC APL L-Type Elbow Fitting APL14-02 Technical Details
- Model: APL14-02
- Type: 90° L-shaped pneumatic connector
- Thread specification: M5×0.8 (male thread both ends)
- Material: Nickel-plated brass (C3604)
- Max working pressure: 1.5 MPa
- Proof pressure: 2.25 MPa
- Burst pressure: ≥3 MPa
- Temperature range: -5℃ to 80℃
- Surface roughness: Ra0.8μm (sealing surfaces)
- Weight: 8.2±0.5g
- Dimensions: 14mm(Length) × 14mm(Width) × 18mm(Height)
- Flow characteristics: CV=0.015
- Vibration resistance: 10-55Hz, 1.5mm amplitude
Precision-machined L-shaped pneumatic fitting with dual O-ring seals (NBR material) for leak-free connections. Features nickel plating for corrosion resistance in humid environments. The compact 90° design enables space-saving plumbing in tight configurations.
Typical Applications:
- Reversing cylinder port connections
- Compact pneumatic manifolds assembly
- Robotic end-effector air routing
- Medical device pneumatic circuits
- Semiconductor equipment air lines
Installation guidance:
Apply thread sealant only on male threads (PTFE tape recommended).
Tightening torque should not exceed 0.25N·m. Rotate fittings by hand
for final 1/4 turn alignment without over-compression.
Compatible components:
- APEM6/APET6 series tubes (ID Φ4mm)
- All AirTAC M5 threaded valves/regulators
- ISO 6149-1 standard adapters
| Property | Property Value |
|---|---|
| sku | APL14-02 |
