Airtac APL L-type Elbow Fitting APL14-03
2、Superior flow performance achieves throughput equivalent to the inner diameter of connected tubing;
3、Features plug-and-play convenience with secure and durable tubing connections;
4、Threads pre-coated with sealing compound, M5 metric threads incorporate sealing gasket for leak-free threaded connections;
5、Nickel-plated brass body provides enhanced resistance to corrosion and contamination, expanding application scope.
Category: L-Type Elbow Fitting , Brand: AIRTAC , Series: APL
AirTAC APL L-Type Elbow Fitting APL14-03 Technical Details
- Model: APL14-03 (L-type 90° elbow)
- Thread type: Male thread (external) to female thread (internal)
- Port size: 1/4" BSPP (G1/4)
- Material: Nickel-plated brass (base material: CuZn39Pb3)
- Max working pressure: 1.5 MPa (217 psi)
- Proof pressure: 2.25 MPa
- Burst pressure: ≥3 MPa
- Temperature range: -5℃ to 80℃ (with NBR seals)
- Seal material: NBR (standard), optional FKM/Viton®
- Surface treatment: Electroless nickel plating (8-12μm)
- Weight: 32±2g
- Dimensions: 25mm (L) × 15mm (W) × 15mm (H)
- Torque specification: 12-15 N·m installation torque
- Compliance: RoHS 2011/65/EU compliant
Precision-engineered L-shaped pneumatic connector designed for 90° directional changes in compact spaces. Features triple-layer nickel plating for corrosion resistance in humid environments. The tapered thread design ensures leak-free connections when properly tightened with PTFE tape or liquid sealant.
- Pneumatic cylinder port redirection in robotic arms
- Space-constrained manifold block installations
- Compressed air tool hose adapters
- CNC machine tool pneumatic circuits
- Semiconductor fab equipment gas lines
Installation tip:
Apply 1.5-2 wraps of PTFE tape clockwise on male threads.
Avoid overtightening - use torque wrench for critical applications.
Maximum angular deviation tolerance: ±3° from 90° axis.
| Property | Property Value |
|---|---|
| sku | APL14-03 |
