Airtac APL L-type Elbow Fitting APL16-02
2、Superior flow performance achieves throughput equivalent to the inner diameter of connected tubing;
3、Features plug-and-play convenience with secure and durable tubing connections;
4、Threads pre-coated with sealing compound, M5 metric threads incorporate sealing gasket for leak-free threaded connections;
5、Nickel-plated brass body provides enhanced resistance to corrosion and contamination, expanding application scope.
Category: L-Type Elbow Fitting , Brand: AIRTAC , Series: APL
AirTAC APL L-Type Elbow Fitting APL16-02 Technical Details
- Model: APL16-02 (L-Type 90° Elbow)
- Thread standard: Metric (M5×0.8) / Optional BSPP (G1/8)
- Material: Nickel-plated brass body
- Seal material: Standard NBR / Optional FKM (Viton®)
- Max working pressure: 1.0 MPa (145 psi)
- Proof pressure: 1.5 MPa
- Burst pressure: 3.0 MPa
- Temperature range: -20℃ to 80℃ (NBR) / -20℃ to 150℃ (FKM)
- Surface treatment: Electroless nickel plating (5-8μm)
- Weight: 24g ±0.5g
- Dimensions: 25mm (L) × 16mm (W) × 16mm (H)
- Flow coefficient (Cv): 0.22
- Compliance: RoHS compliant / REACH certified
Precision-machined L-shaped pneumatic connector with leak-proof design, featuring dual O-ring seals and hexagon wrench flats for secure installation. The compact 90° configuration enables space-saving plumbing in complex pneumatic circuits. Nickel plating provides corrosion resistance in humid environments.
- Pneumatic valve manifold interconnections
- Robotic arm tooling air supply lines
- CNC machine tool clamping systems
- Medical device pneumatic controls
- Packaging machine actuator networks
Installation guidelines:
Apply 2-3 wraps of PTFE tape on male threads (do not over-tighten beyond 1.5 N·m torque).
Avoid angular stress by maintaining proper tube alignment. Compatible with Ø4mm or 1/8" tubing.
| Property | Property Value |
|---|---|
| sku | APL16-02 |
