Airtac APL L-type Elbow Fitting APL16-03
2、Superior flow performance achieves throughput equivalent to the inner diameter of connected tubing;
3、Features plug-and-play convenience with secure and durable tubing connections;
4、Threads pre-coated with sealing compound, M5 metric threads incorporate sealing gasket for leak-free threaded connections;
5、Nickel-plated brass body provides enhanced resistance to corrosion and contamination, expanding application scope.
Category: L-Type Elbow Fitting , Brand: AIRTAC , Series: APL
AirTAC APL L-Type Elbow Fitting APL16-03 Technical Details
- Model: APL16-03 (L-type 90° elbow)
- Thread type: G1/8 (BSPP parallel) female threads
- Material: Nickel-plated brass body
- Seal material: NBR (Nitrile) O-rings
- Max working pressure: 1.5 MPa (217 psi)
- Proof pressure: 3.0 MPa
- Burst pressure: ≥6.0 MPa
- Temperature range: -5℃ to 80℃ (with NBR seals)
- Surface treatment: Electroplated zinc-nickel alloy (ISO 4525 compliant)
- Weight: 18.5g ±0.5g
- Dimensions: 23mm(A) × 16mm(B) × 16mm(C)
(A=total height, B=port-to-port distance, C=hex width) - Torque specification: 1.2-1.5 N·m during installation
Precision-machined L-shaped pneumatic connector featuring zero-leak design with dual NBR sealing rings. The compact 90° configuration enables space-saving plumbing in tight assemblies. Nickel plating provides corrosion resistance in humid environments while maintaining electrical conductivity for grounding.
- Pneumatic cylinder port redirection in robotic arms
- Compact valve manifolds requiring angled connections
- Air tool plumbing with vibration resistance needs
- Medical equipment gas line routing
- Packaging machine sensor air supply lines
Installation guidelines:
Apply thread sealant only on male threads (not required for BSPP).
Avoid overtightening - use crowfoot wrench on hex flats for precise torque control.
Perform pressure test at 1.25× working pressure after installation.
| Property | Property Value |
|---|---|
| sku | APL16-03 |
