Airtac APL L-type Elbow Fitting APL16-06
$11.59
Regular price
$19.09
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APL16-06
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Available in multiple models and specifications, widely applicable to various pneumatic systems;
2、Superior flow performance achieves throughput equivalent to the inner diameter of connected tubing;
3、Features plug-and-play convenience with secure and durable tubing connections;
4、Threads pre-coated with sealing compound, M5 metric threads incorporate sealing gasket for leak-free threaded connections;
5、Nickel-plated brass body provides enhanced resistance to corrosion and contamination, expanding application scope.
Category: L-Type Elbow Fitting , Brand: AIRTAC , Series: APL
Installation protocol:
Insert tubing until it bottoms out, then pull back slightly (1-1.5mm) to engage retention mechanism.
Apply 1.2-1.5N·m torque during threading. For vacuum applications, use silicone-based sealant on male threads.
2、Superior flow performance achieves throughput equivalent to the inner diameter of connected tubing;
3、Features plug-and-play convenience with secure and durable tubing connections;
4、Threads pre-coated with sealing compound, M5 metric threads incorporate sealing gasket for leak-free threaded connections;
5、Nickel-plated brass body provides enhanced resistance to corrosion and contamination, expanding application scope.
Category: L-Type Elbow Fitting , Brand: AIRTAC , Series: APL
AirTAC APL Series L-Type Elbow Fitting APL16-06 Technical Details
- Model: APL16-06 (L-Type 90° Elbow)
- Thread standard: Metric (M5×0.8 male thread)
- Material: Nickel-plated brass (C3604)
- Seal type: Precision-molded NBR O-ring
- Max working pressure: 1.0 MPa (145 psi)
- Temperature range: -5℃ to 80℃ (with NBR seals)
- Tube compatibility: 6mm OD polyurethane/nylon tubing
- Surface treatment: Electroless nickel plating (8-12μm thickness)
- Weight: 24g ±0.5g
- Dimensions: 20mm (L) × 20mm (W) × 25mm (H)
- Vibration resistance: ≤10Hz frequency, 1.5mm amplitude
- Leakage rate: <0.1 bubbles/min under 0.5MPa air pressure
Precision-engineered L-shaped pneumatic connector featuring anti-vibration teeth for secure tubing retention. The electroless nickel plating provides corrosion resistance in humid environments, while the 45° swivel design enables flexible orientation adjustments post-installation.
Ideal Applications:
- Compact pneumatic circuit layouts in robotic grippers
- Space-constrained CNC machine tool manifolds
- Modular pneumatic training systems
- Food processing equipment (non-direct contact areas)
- Semiconductor manufacturing gas lines
Installation protocol:
Insert tubing until it bottoms out, then pull back slightly (1-1.5mm) to engage retention mechanism.
Apply 1.2-1.5N·m torque during threading. For vacuum applications, use silicone-based sealant on male threads.
Compatibility alert:
Not recommended for use with phosphate ester-based hydraulic fluids or chlorinated solvents.
Periodic inspection cycle: 6 months in standard environments, 3 months in high-vibration/humidity conditions.
| Property | Property Value |
|---|---|
| sku | APL16-06 |
