Airtac APL L-type Elbow Fitting APL16-M20
2、Superior flow performance achieves throughput equivalent to the inner diameter of connected tubing;
3、Features plug-and-play convenience with secure and durable tubing connections;
4、Threads pre-coated with sealing compound, M5 metric threads incorporate sealing gasket for leak-free threaded connections;
5、Nickel-plated brass body provides enhanced resistance to corrosion and contamination, expanding application scope.
Category: L-Type Elbow Fitting , Brand: AIRTAC , Series: APL
AirTAC APL Series L-Type Elbow Fitting APL16-M20 Technical Details
- Model: APL16-M20 (L-Type 90° Elbow)
- Thread Specification: M20×1.5 (Metric Fine Thread)
- Material: Lead-Free Brass (CuZn39Pb3) with Nickel Plating
- Pressure Rating: 0.05-1.0 MPa (Operating), 1.5 MPa Burst Pressure
- Temperature Range: -20℃ to 120℃ (Dry Air), -5℃ to 80℃ (Lubricated)
- Surface Roughness: Ra ≤3.2μm (Internal Flow Path)
- Installation Torque: 25-30 N·m (Dry Seal), 18-22 N·m (With PTFE Tape)
- Weight: 148±5g (With Protective Caps)
- Dimensions: 46mm(A) × 34mm(B) × 28mm(C) (L×W×H)
- Flow Coefficient: Cv=0.38 (At 6 bar)
- Seal Type: Dual O-Ring Design (NBR Material)
- Vibration Resistance: 10-55Hz, 1.5mm Amplitude
- Certifications: RoHS Compliant, REACH SVHC <0.1%
Precision-machined L-shaped pneumatic connector featuring anti-vibration grooves and color-coded sealing rings (blue for air intake, black for exhaust). The asymmetrical port design prevents misalignment during manifold assembly. Includes dust-resistant nylon caps pre-installed on both ports.
- Pneumatic cylinder manifold blocks in packaging lines
- Tool-changing mechanisms for CNC machining centers
- Compressed air distribution in automotive assembly robots
- Vacuum circuit connections for glass handling systems
- Modular pneumatic teaching platforms for technical education
Installation Protocol:
Apply thread sealant only on male threads, avoid overtightening beyond 30° rotation after hand-tight.
For vertical installations, position O-rings facing downward to prevent debris accumulation.
Torque sequence should follow cross pattern when mounting multiple fittings.
| Property | Property Value |
|---|---|
| sku | APL16-M20 |
