Airtac APL L-type Elbow Fitting APL4-02
2、Superior flow performance achieves throughput equivalent to the inner diameter of connected tubing;
3、Features plug-and-play convenience with secure and durable tubing connections;
4、Threads pre-coated with sealing compound, M5 metric threads incorporate sealing gasket for leak-free threaded connections;
5、Nickel-plated brass body provides enhanced resistance to corrosion and contamination, expanding application scope.
Category: L-Type Elbow Fitting , Brand: AIRTAC , Series: APL
AirTAC APL Series L-Type Elbow Fitting APL4-02 Technical Details
- Model: APL4-02 (L-Type 90° Elbow)
- Body material: Brass with nickel plating (stainless steel optional)
- Port size: PT1/8 (BSPP) / NPT1/8 available
- Thread type: Female-Female configuration
- Operating pressure: 0.1-1.0 MPa (14.5-145 PSI)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Seal material: NBR (Nitrile) standard, FKM (Viton) optional
- Surface treatment: Electroless nickel plating (3-5μm thickness)
- Proof pressure: 1.5 MPa (217.5 PSI)
- Weight: 18.5g ±0.3g
- Dimensions: 16mm (L) × 16mm (W) × 18mm (H)
- Thread engagement depth: 8mm per port
- Flow coefficient (Cv): 0.3
- Vibration resistance: 10-55Hz, 1.5mm amplitude
Precision-engineered L-shaped pneumatic connector enabling 90° flow direction change in compact installations. Features triple-layer nickel plating for corrosion resistance in humid environments. The internal 0.8mm flow path minimizes pressure drop while maintaining structural integrity.
- Robotic arm pneumatic circuit routing
- CNC machine tool air line connections
- Medical device pneumatic systems requiring compact layouts
- Food processing equipment (stainless steel version)
- Semiconductor manufacturing pneumatic controls
- High-cycle automation fixtures (tested for 500,000+ rotations)
Installation protocol:
Apply 2-3 wraps of PTFE tape clockwise on male threads.
Tighten to 1.2-1.5N·m torque using crowfoot wrench.
Avoid overtightening which may crack sealing surfaces.
| Property | Property Value |
|---|---|
| sku | APL4-02 |
