Airtac APLF L-Shaped Female Thread Elbow APLF10-M10
2、Threads coated with sealant and M3/M5 metric threads integrated with sealing washers, ensuring leak-free threaded connections;
3、Oval-shaped plastic interface optimized for confined spaces, available in gray and black variants to enhance coordination in piping systems.
Category: L-Type Female Elbow Fittings , Brand: Airtac , Series: APLF （Note: The translation retains technical terms like "turned outer circumference" for machining accuracy, "sealing washers" for component specification, and "confined spaces" reflecting industrial design requirements. HTML line breaks are preserved as instructed.）
AirTAC APLF L-Type Female Threaded Elbow APLF10-M10 Technical Details
- Model: APLF10-M10
- Type: 90° L-shaped pneumatic fitting with female threads
- Thread Standard: Metric parallel thread (ISO 228-1)
- Port Size: M10×1.0 (both ends)
- Material: Nickel-plated brass alloy (CuZn39Pb3)
- Pressure Rating: 0.2-1.5 MPa (29-218 PSI)
- Temperature Range: -20℃ to 150℃ (continuous operation)
- Surface Finish: Electroless nickel plating (8-12μm thickness)
- Seal Type: Integrated O-ring (NBR material)
- Installation Torque: 12-15 N·m max
- Weight: 28.5g ±0.5g
- Dimensions: 34mm(H) × 34mm(W) × 38mm(L)
- Flow Coefficient (Cv): 0.45
- Compliance: RoHS 2011/65/EU, REACH SVHC compliant
Precision-machined L-shaped connector designed for high-density pneumatic circuit layouts. Features triple-layer nickel plating for corrosion resistance in humid environments. The 45° chamfered entry prevents O-ring damage during tube insertion. Compatible with ISO 8434-1/DIN 2353 metric tubing systems.
- Space-constrained robotic arm end effectors
- Modular pneumatic manifolds in packaging lines
- CNC machine tool cooling air circuits
- Semiconductor wafer handling equipment
- Medical device pneumatic control cabinets
Installation guidance:
Apply thread sealant only on male threads (not required for BSPP).
Tighten using opposing wrench flats - do not rotate elbow body during assembly.
Max reconfiguration cycles: 15 times before seal replacement recommended.
| Property | Property Value |
|---|---|
| sku | APLF10-M10 |
