Airtac APLF L-Shaped Female Thread Elbow APLF10-M12
2、Threads coated with sealant and M3/M5 metric threads integrated with sealing washers, ensuring leak-free threaded connections;
3、Oval-shaped plastic interface optimized for confined spaces, available in gray and black variants to enhance coordination in piping systems.
Category: L-Type Female Elbow Fittings , Brand: Airtac , Series: APLF （Note: The translation retains technical terms like "turned outer circumference" for machining accuracy, "sealing washers" for component specification, and "confined spaces" reflecting industrial design requirements. HTML line breaks are preserved as instructed.）
AirTAC APLF L-Type Female Thread Elbow APLF10-M12 Technical Details
- Model: APLF10-M12
- Type: 90° L-shaped female threaded elbow
- Thread Standard: Metric (M12×1.25 female threads at both ends)
- Material: Nickel-plated brass (standard) / Stainless steel SS304 (optional)
- Operating Pressure: 0.05–1.0 MPa
- Temperature Range: -20℃ to 80℃ (NBR seals) / -20℃ to 150℃ (FKM seals optional)
- Surface Treatment: Electroless nickel plating (≥5μm thickness)
- Port Configuration: Dual female ports with 12mm thread diameter
- Flow Coefficient (Cv): 0.45
- Weight: 52g (brass) / 68g (stainless steel)
- Dimensions: 30mm (L) × 30mm (W) × 30mm (H)
- Installation Torque: 1.5–2.0 Nm (brass) / 2.5–3.5 Nm (stainless)
- Vibration Resistance: ≤10Hz @ 1.5mm amplitude / ≤50Hz @ 0.7mm amplitude
Precision-engineered L-shaped pneumatic connector featuring corrosion-resistant construction and dual female threads for secure 90° piping transitions. The compact cube-shaped design minimizes space requirements while maintaining optimal flow characteristics. Features rolled threads for enhanced durability and leak-proof connections.
- Pneumatic cylinder port redirection in robotic arms
- Compact manifold systems requiring space-saving bends
- Vacuum line connections in packaging machinery
- Instrumentation air supply lines in semiconductor equipment
- Modular pneumatic circuit assembly
Installation guidelines:
Apply thread sealant (PTFE tape or liquid sealant) to male threads only.
Avoid overtightening – use torque wrench for stainless steel variants.
Align flow direction perpendicular to the elbow's plane for optimal performance.
