Airtac APLF L-Shaped Female Thread Elbow APLF10-M20
2、Threads coated with sealant and M3/M5 metric threads integrated with sealing washers, ensuring leak-free threaded connections;
3、Oval-shaped plastic interface optimized for confined spaces, available in gray and black variants to enhance coordination in piping systems.
Category: L-Type Female Elbow Fittings , Brand: Airtac , Series: APLF （Note: The translation retains technical terms like "turned outer circumference" for machining accuracy, "sealing washers" for component specification, and "confined spaces" reflecting industrial design requirements. HTML line breaks are preserved as instructed.）
AirTAC APLF L-Type Female Threaded Elbow APLF10-M20 Technical Details
- Model: APLF10-M20
- Type: 90° L-shaped pneumatic fitting with female threads
- Thread specification: M20×1.5 internal threads (both ports)
- Material: Nickel-plated brass (CuZn39Pb3)
- Seal material: NBR (Nitrile) O-ring
- Temperature range: -20℃ to 80℃ (continuous use)
- Pressure range: 0.2-1.5 MPa (2-15 bar)
- Corrosion resistance: 500hr neutral salt spray test compliant
- Installation orientation: Omnidirectional (360° rotatable)
- Certification: ISO 8434-1/DIN 3861 standards
- Weight: 48g ±2g
- Dimensions: 40mm(L) × 40mm(W) × 32mm(H)
Precision-machined L-connector designed for high-density pneumatic systems requiring space optimization. Features self-aligning threads and dual O-ring seals for vibration resistance. The nickel plating provides enhanced wear resistance, with 200% higher cycle life compared to standard brass fittings.
- Robotic arm pneumatic circuit redirection
- CNC machine tool air line configurations
- Packaging machinery compact piping systems
- Semiconductor manufacturing equipment
- Medical device pneumatic control units
Installation protocol:
Apply 1.5-2 wraps of PTFE tape on male threads (do not over-tighten - max torque 15N·m).
For vertical downward flow applications, install drain port facing downward.
Pressure test at 1.8MPa after assembly.
| Property | Property Value |
|---|---|
| sku | APLF10-M20 |
