Airtac APLF L-Shaped Female Thread Elbow APLF12-02
2、Threads coated with sealant and M3/M5 metric threads integrated with sealing washers, ensuring leak-free threaded connections;
3、Oval-shaped plastic interface optimized for confined spaces, available in gray and black variants to enhance coordination in piping systems.
Category: L-Type Female Elbow Fittings , Brand: Airtac , Series: APLF （Note: The translation retains technical terms like "turned outer circumference" for machining accuracy, "sealing washers" for component specification, and "confined spaces" reflecting industrial design requirements. HTML line breaks are preserved as instructed.）
AirTAC APLF L-Type Female Thread Elbow APLF12-02 Technical Details
- Model: APLF12-02 (L-Type 90° Elbow)
- Thread Type: Female Thread (Internal)
- Port Size: PT1/8 (R1/8) / G1/8 (BSPP)
- Material: Brass (Nickel-plated) / Optional SS304
- Surface Treatment: Electroplated (Standard anti-corrosion layer)
- Pressure Range: 0.05-1.0 MPa
- Temperature Range: -5℃ to 80℃
- Seal Material: NBR (Nitrile Rubber)
- Thread Tolerance: Class B (JIS B 0203)
- Weight: 24g ±1g (Brass version)
- Dimensions: 21.5mm(L) × 18.2mm(W) × 21.5mm(H)
- Flow Coefficient: Cv≈0.3
- Vibration Resistance: ≤10-55Hz, 1.5mm amplitude
- Certification: RoHS compliant
A precision-engineered L-shaped pneumatic fitting providing 90° flow direction change with leak-proof performance. Features dual-port sealing structure with embedded O-ring for bidirectional pressure containment. The hexagonal base allows tool tightening (recommended torque: 1.2-1.5N·m).
- Compact pneumatic circuit layouts in robotics
- Space-constrained actuator connections
- Modular pneumatic manifold systems
- Medical equipment gas line routing
- CNC machine tool air supply networks
Installation guidelines:
Apply thread sealant (Loctite 5452 recommended) to male threads before assembly.
Avoid overtightening - maximum 1.8N·m torque. Perform pressure test at 1.5x working
pressure after installation. Compatible with ISO 1179-2 and JIS B 0203 standards.
| Property | Property Value |
|---|---|
| sku | APLF12-02 |
