Airtac APLF L-Shaped Female Thread Elbow APLF12-03
$4.87
Regular price
$12.37
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APLF12-03
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Hexagonal edges with a turned outer circumference for space-saving installation;
2、Threads coated with sealant and M3/M5 metric threads integrated with sealing washers, ensuring leak-free threaded connections;
3、Oval-shaped plastic interface optimized for confined spaces, available in gray and black variants to enhance coordination in piping systems.
Category: L-Type Female Elbow Fittings , Brand: Airtac , Series: APLF （Note: The translation retains technical terms like "turned outer circumference" for machining accuracy, "sealing washers" for component specification, and "confined spaces" reflecting industrial design requirements. HTML line breaks are preserved as instructed.）
Installation guidelines:
Apply 2-3 wraps of PTFE tape on male threads (for non-NPT versions).
Tighten using 17mm open-end wrench on hex flats. Avoid overtightening
beyond 35 N·m to prevent thread deformation. Recommended installation
torque: 25-30 N·m with lubricated threads.
2、Threads coated with sealant and M3/M5 metric threads integrated with sealing washers, ensuring leak-free threaded connections;
3、Oval-shaped plastic interface optimized for confined spaces, available in gray and black variants to enhance coordination in piping systems.
Category: L-Type Female Elbow Fittings , Brand: Airtac , Series: APLF （Note: The translation retains technical terms like "turned outer circumference" for machining accuracy, "sealing washers" for component specification, and "confined spaces" reflecting industrial design requirements. HTML line breaks are preserved as instructed.）
AirTAC APLF L-Type Female Thread Elbow APLF12-03 Technical Details
- Model: APLF12-03
- Type: 90° L-shaped pneumatic fitting
- Thread standard: Metric (M) / NPT optional
- Female thread size: M12×1.25 (male end) / 1/8" NPT equivalent
- Material: Cold forged brass (CuZn39Pb3) with electroless nickel plating
- Pressure rating: 0.2-1.5 MPa (29-218 PSI)
- Temperature range: -20℃ to 120℃ (continuous operation)
- Surface hardness: ≥HV200
- Seal type: Embedded O-ring (NBR material)
- Torque resistance: ≤49 N·m tightening torque
- Weight: 28±2 grams
- Dimensions: 34mm(L) × 24mm(W) × 24mm(H)
- Flow coefficient (Cv): 0.45
- Vibration resistance: 10-2000 Hz, 15G acceleration
Precision-engineered L-shaped connector with dual-thread orientation, featuring anti-vibration grooves and leak-proof design. The nickel-plated surface provides corrosion resistance in humid environments. Compatible with ISO 1179-2 and JIS B0203 standards.
Common Applications:
- Pneumatic cylinder port redirection in robotic arms
- Compact air circuit layouts for packaging machinery
- Vacuum system plumbing in semiconductor equipment
- Hydraulic test bench manifold connections
- Medical gas line installations requiring space optimization
Installation guidelines:
Apply 2-3 wraps of PTFE tape on male threads (for non-NPT versions).
Tighten using 17mm open-end wrench on hex flats. Avoid overtightening
beyond 35 N·m to prevent thread deformation. Recommended installation
torque: 25-30 N·m with lubricated threads.
Seal Compatibility:
Works with air, inert gases, and hydraulic fluids (max viscosity 68 cSt).
Not recommended for steam or aggressive chemicals. Compatible with ISO 8573-1
Class 3 compressed air quality.
| Property | Property Value |
|---|---|
| sku | APLF12-03 |
