Airtac APLF L-Shaped Female Thread Elbow APLF12-M12
2、Threads coated with sealant and M3/M5 metric threads integrated with sealing washers, ensuring leak-free threaded connections;
3、Oval-shaped plastic interface optimized for confined spaces, available in gray and black variants to enhance coordination in piping systems.
Category: L-Type Female Elbow Fittings , Brand: Airtac , Series: APLF （Note: The translation retains technical terms like "turned outer circumference" for machining accuracy, "sealing washers" for component specification, and "confined spaces" reflecting industrial design requirements. HTML line breaks are preserved as instructed.）
AirTAC APLF L-Type Female Thread Elbow APLF12-M12 Technical Details
- Model: APLF12-M12
- Type: 90° L-shaped female threaded elbow
- Thread Standard: Metric fine thread (M12×1.25)
- Material: Lead-free brass CW617N (RoHS compliant)
- Surface Treatment: Electroplated nickel (8-12μm thickness)
- Pressure Rating: 0.2-1.5 MPa (29-217 PSI)
- Temperature Range: -20℃ to 120℃ (static), -5℃ to 80℃ (dynamic)
- Seal Type: Integrated O-ring (NBR material, hardness 70±5 Shore A)
- Flow Coefficient (Cv): 0.45
- Weight: 153g ±2% (including packaging)
- Dimensions: 32mm(L) × 28mm(W) × 35mm(H)
- Torque Specification: 14-16 N·m during installation
- Compatibility: Works with ISO 1179-2 and DIN 3852-E fittings
Precision-engineered L-shaped connector enabling 90° directional changes in pneumatic systems. Features anti-vibration grooves and dual-stage sealing (metal-to-metal + elastic seal). The nickel plating provides corrosion resistance exceeding 96hrs in salt spray tests. Internal bore maintains 4.8mm diameter for minimal pressure drop.
- Robotic arm pneumatic circuit routing
- CNC machine tool air supply manifolds
- Packaging line actuator connections
- Semiconductor equipment gas delivery systems
- Automotive brake line test benches
Installation protocol:
Apply PTFE tape on male threads (2.5 wraps minimum) before assembly.
Use counter-rotation technique during tightening to prevent seal twist.
Avoid side-load stresses - support tubing within 150mm of fitting.
| Property | Property Value |
|---|---|
| sku | APLF12-M12 |
