Airtac APLF L-Shaped Female Thread Elbow APLF12-M20
$5.39
Regular price
$12.89
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APLF12-M20
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Hexagonal edges with a turned outer circumference for space-saving installation;
2、Threads coated with sealant and M3/M5 metric threads integrated with sealing washers, ensuring leak-free threaded connections;
3、Oval-shaped plastic interface optimized for confined spaces, available in gray and black variants to enhance coordination in piping systems.
Category: L-Type Female Elbow Fittings , Brand: Airtac , Series: APLF （Note: The translation retains technical terms like "turned outer circumference" for machining accuracy, "sealing washers" for component specification, and "confined spaces" reflecting industrial design requirements. HTML line breaks are preserved as instructed.）
Installation guidelines:
Apply 2-3 wraps of PTFE tape on male threads (do not over-tighten beyond 30 N·m).
For vertical installations, position O-rings facing upward to prevent debris accumulation.
Maximum recommended torque for tube insertion: 3.5 N·m using 12mm OD tubing.
2、Threads coated with sealant and M3/M5 metric threads integrated with sealing washers, ensuring leak-free threaded connections;
3、Oval-shaped plastic interface optimized for confined spaces, available in gray and black variants to enhance coordination in piping systems.
Category: L-Type Female Elbow Fittings , Brand: Airtac , Series: APLF （Note: The translation retains technical terms like "turned outer circumference" for machining accuracy, "sealing washers" for component specification, and "confined spaces" reflecting industrial design requirements. HTML line breaks are preserved as instructed.）
AirTAC APLF L-Type Female Thread Elbow APLF12-M20 Technical Details
- Model: APLF12-M20
- Type: 90° L-shaped pneumatic fitting with female threads
- Material: Aluminum alloy 6063-T5
- Surface treatment: Anodized (natural color)
- Thread specification: M20×1.5 metric internal thread (ISO 6149 compliant)
- Pressure rating: 0.05-1.6 MPa (7-232 psi)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Seal material: NBR (Nitrile) rubber
- Flow coefficient (Cv): 0.45
- Weight: 0.28 kg (0.62 lbs)
- Dimensions: 52mm(L) × 52mm(W) × 32mm(H)
- Port alignment: Orthogonal 90° configuration
- Vibration resistance: ≤10 Hz (axial direction)
- Corrosion resistance: 96hr salt spray test passed
Precision-machined L-shaped connector enabling compact 90° piping layouts in pneumatic systems. Features dual O-ring grooves with NBR seals for leak-proof connections. The anodized surface provides enhanced wear resistance against tube insertion/removal operations.
Typical Applications:
- Robotic arm pneumatic circuit redirection
- CNC machine tool air supply manifolds
- Packaging equipment air cylinder plumbing
- Semiconductor fab cleanroom systems
- Elevator brake pneumatic line configurations
Installation guidelines:
Apply 2-3 wraps of PTFE tape on male threads (do not over-tighten beyond 30 N·m).
For vertical installations, position O-rings facing upward to prevent debris accumulation.
Maximum recommended torque for tube insertion: 3.5 N·m using 12mm OD tubing.
Compatible Accessories:
- AirTAC PIS12 series push-to-connect fittings
- ASM12 modular manifold systems
- APET series threaded plugs
- 12mm OD polyurethane/nylon tubing
| Property | Property Value |
|---|---|
| sku | APLF12-M20 |
