Airtac APLF L-Shaped Female Thread Elbow APLF14-04
2、Threads coated with sealant and M3/M5 metric threads integrated with sealing washers, ensuring leak-free threaded connections;
3、Oval-shaped plastic interface optimized for confined spaces, available in gray and black variants to enhance coordination in piping systems.
Category: L-Type Female Elbow Fittings , Brand: Airtac , Series: APLF （Note: The translation retains technical terms like "turned outer circumference" for machining accuracy, "sealing washers" for component specification, and "confined spaces" reflecting industrial design requirements. HTML line breaks are preserved as instructed.）
AirTAC APLF L-Type Female Thread Elbow APLF14-04 Technical Details
- Model: APLF14-04
- Type: 90° L-shaped pneumatic connector
- Thread Standard: Metric (M)
- Female Thread Size: M14×1.5 internal
- Male Thread Size: M14×1.5 external
- Material: Brass with nickel plating
- Seal Material: NBR (Nitrile) O-ring
- Max Working Pressure: 1.5 MPa (15 bar)
- Temperature Range: -20℃ to +80℃
- Surface Hardness: HV0.3 ≥320
- Weight: 38±2 grams
- Dimensions:
- Total Length: 46.5mm
- Thread Engagement Length: 12mm (both ends)
- Center-to-Center Distance: 28mm (between port axes)
- Hex Size: 19mm wrench flat
- Corrosion Resistance: 96hrs neutral salt spray test passed
Precision-machined L-shaped pneumatic fitting designed for high-pressure pneumatic systems. Features anti-vibration grooves and triple-sealing structure (thread seal + O-ring + metal-to-metal contact). The electroless nickel plating ensures corrosion resistance while maintaining electrical conductivity for grounding purposes.
- Pneumatic cylinder port redirection in tight spaces
- Compact manifold block connections
- Robotic arm pneumatic circuit routing
- CNC machine tool air supply systems
- Packaging equipment air line management
Installation guidelines:
Apply thread sealant only on male threads (PTFE tape or liquid sealant).
Tighten to 25-30 N·m torque using calibrated wrench. Avoid overtightening
which may distort O-ring groove geometry. Perform pressure test at 1.8MPa
after installation.
| Property | Property Value |
|---|---|
| sku | APLF14-04 |
