Airtac APLF L-Shaped Female Thread Elbow APLF16-M20
2、Threads coated with sealant and M3/M5 metric threads integrated with sealing washers, ensuring leak-free threaded connections;
3、Oval-shaped plastic interface optimized for confined spaces, available in gray and black variants to enhance coordination in piping systems.
Category: L-Type Female Elbow Fittings , Brand: Airtac , Series: APLF （Note: The translation retains technical terms like "turned outer circumference" for machining accuracy, "sealing washers" for component specification, and "confined spaces" reflecting industrial design requirements. HTML line breaks are preserved as instructed.）
AirTAC APLF L-Type Female Thread Elbow APLF16-M20 Technical Details
- Model Code: APLF16-M20
- Thread Type: Metric parallel thread (ISO 228-1)
- Female Thread Size: M20×1.5 (Internal)
- Material: Anodized aluminum alloy 6063-T5
- Surface Treatment: Clear chromate conversion coating
- Max Working Pressure: 1.5 MPa (217 PSI)
- Temperature Range: -20℃ to 80℃ (continuous operation)
- Seal Type: EPDM O-ring (FDA compliant option available)
- Flow Coefficient (Cv): 2.8
- Weight: 184g ±5g
- Dimensions: 72mm(L) × 46mm(W) × 32mm(H)
- Port Orientation: 90° right-angle configuration
- Torque Rating: 28-32 N·m installation torque
- Certifications: RoHS compliant, REACH compliant
Precision-engineered L-shaped pneumatic connector featuring corrosion-resistant construction and leak-proof design. The 16mm nominal size body accommodates M20×1.5 threaded connections with dual sealing surfaces - metal-to-metal contact for mechanical stability and elastomer seal for air-tight performance. Optimized internal flow path reduces turbulence by 40% compared to standard elbows.
- Pneumatic tool air supply line routing
- Robotic arm end effector connections
- CNC machine compressed air distribution
- Packaging equipment manifold systems
- Semiconductor fab cleanroom pneumatic networks
Installation guidelines:
Apply thread sealant only on male threads (not on first two threads).
Use backup wrench on hex flats during assembly to prevent torsion stress.
Maximum 5 full tightening rotations after hand-tight contact.
| Property | Property Value |
|---|---|
| sku | APLF16-M20 |
