Airtac APLF L-Shaped Female Thread Elbow APLF4-02
2、Threads coated with sealant and M3/M5 metric threads integrated with sealing washers, ensuring leak-free threaded connections;
3、Oval-shaped plastic interface optimized for confined spaces, available in gray and black variants to enhance coordination in piping systems.
Category: L-Type Female Elbow Fittings , Brand: Airtac , Series: APLF （Note: The translation retains technical terms like "turned outer circumference" for machining accuracy, "sealing washers" for component specification, and "confined spaces" reflecting industrial design requirements. HTML line breaks are preserved as instructed.）
AirTAC APLF L-Type Female Threaded Elbow APLF4-02 Technical Details
- Model: APLF4-02 (L-type 90° elbow)
- Thread type: Metric parallel female threads (BSPP available on request)
- Port configuration: Dual female threads (input/output same size)
- Thread size: M5×0.8 (ISO 228 standard)
- Material: Brass CW617N with electroless nickel plating (8-12μm)
- Pressure rating: 0.2-1.5 MPa (29-217 PSI)
- Burst pressure: ≥6.0 MPa
- Temperature range: -20℃ to 120℃ (continuous operation)
- Seal material: HNBR (Hydrogenated Nitrile) O-rings
- Surface roughness: Ra ≤1.6μm (internal flow path)
- Weight: 18.5±0.3 grams
- Dimensions: 25mm(A) × 25mm(B) × 20mm(C) (L×W×H)
- Center-to-center port distance: 16mm±0.15mm
- Corrosion resistance: 96hrs neutral salt spray test passed
Precision-machined L-shaped pneumatic connector enabling 90° directional changes in compact installations. Features anti-vibration thread locking design with dual sealing surfaces (metal-to-metal + elastic seal). Internal flow path optimized for minimal pressure drop (ΔP <0.01MPa @1MPa). Compatible with ISO 1179 and DIN 3852 standards.
- Space-constrained pneumatic manifolds
- Robotic end-effector tooling air supply
- Medical device gas line connections
- CNC machine coolant control systems
- Semiconductor fab equipment plumbing
Installation protocol:
Apply thread sealant (PTFE tape or LOCTITE 577) on male threads only.
Tightening torque: 1.2-1.5N·m (do not exceed 2.0N·m).
Perform pressure test at 1.25× working pressure after installation.
| Property | Property Value |
|---|---|
| sku | APLF4-02 |
