Airtac APLF L-Shaped Female Thread Elbow APLF4-M12
2、Threads coated with sealant and M3/M5 metric threads integrated with sealing washers, ensuring leak-free threaded connections;
3、Oval-shaped plastic interface optimized for confined spaces, available in gray and black variants to enhance coordination in piping systems.
Category: L-Type Female Elbow Fittings , Brand: Airtac , Series: APLF （Note: The translation retains technical terms like "turned outer circumference" for machining accuracy, "sealing washers" for component specification, and "confined spaces" reflecting industrial design requirements. HTML line breaks are preserved as instructed.）
AirTAC APLF L-Type Female Thread Elbow APLF4-M12 Technical Details
- Model: APLF4-M12
- Thread type: Metric female threads (internal)
- Thread size: M12×1.25 (ISO standard pitch)
- Material: Lead-free brass CW617N (nickel-plated surface)
- Seal type: Integrated NBR O-ring (oil/water resistant)
- Temperature range: -20℃ to +80℃ (continuous operation)
- Pressure rating: 0.5 MPa ~ 1.6 MPa (5 bar ~ 16 bar)
- Flow capacity: 450 NL/min (at 0.5 MPa pressure drop)
- Surface finish: Electroless nickel plating (8-12μm thickness)
- Weight: 24.5g ±0.3g (without packaging)
- Dimensions: 20mm (L) × 20mm (W) × 28mm (H)
- Angular tolerance: ±1° (90° bend accuracy)
- Compliance: RoHS 2.0, REACH, ISO 1179-1 standard
- Color code: Natural metallic (nickel finish)
Precision-engineered L-shaped pneumatic connector designed for 90° flow direction changes in compact installations. Features corrosion-resistant nickel plating and dual-sealing structure (metal-to-metal + elastic seal) for leak-free performance in high-vibration environments. The internal flow path is optimized for minimal pressure drop.
- Pneumatic cylinder port redirection in robotic arms
- Space-constrained piping layouts in packaging machinery
- Modular pneumatic circuit assemblies
- Compressed air tool connections
- Medical equipment gas line routing
Installation protocol:
Hand-tighten initially, then apply 1/4~1/2 additional turn with wrench.
Use liquid thread sealant (LOCTITE 577 recommended) for high-pressure systems.
Avoid overtightening (max torque 14 N·m).
Compatible with ISO 1179-1 and DIN 3852-E metric thread standards
| Property | Property Value |
|---|---|
| sku | APLF4-M12 |
