Airtac APU Straight Quick Plug Connector APU12
$3.32
Regular price
$10.82
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APU12
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、This product series is entirely copper-free, making it suitable for direct application in copper-restricted environments;
2、Available in multiple configurations and specifications, widely compatible with various pneumatic systems;
3、Superior flow performance achieves throughput capacity matching the inner diameter of connected tubing;
4、Features quick-connect/disconnect mechanism for efficient tube installation, ensuring secure leak-resistant connections with enhanced durability.
Category: Threaded Type One-way Flow Control Valve , Brand: AirTAC , Series: APU
Installation protocol:
Cut tubing square (max 0.5° angle tolerance), insert fully until audible click.
For stainless steel version, apply thread sealant on male threads.
Requires 40μm filtered air/oil mist (ISO 8573-1 Class 4.4.2).
2、Available in multiple configurations and specifications, widely compatible with various pneumatic systems;
3、Superior flow performance achieves throughput capacity matching the inner diameter of connected tubing;
4、Features quick-connect/disconnect mechanism for efficient tube installation, ensuring secure leak-resistant connections with enhanced durability.
Category: Threaded Type One-way Flow Control Valve , Brand: AirTAC , Series: APU
AirTAC APU12 Straight Through Quick Connector Specifications
- Model: APU12 Series
- Type: Straight-through push-to-connect fitting
- Body material: Brass (nickel-plated) / Stainless steel option
- Seal material: NBR (Nitrile) / FKM (Fluorocarbon) optional
- Thread standard: G1/8 (BSPP) / M5×0.8 metric thread available
- Operating pressure: 0.3-1.5 MPa (43.5-217.5 PSI)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Flow rate: 350 NL/min at 0.5 MPa
- Tube compatibility: Ø4mm (5/32") OD pneumatic tubing
- Leakage: <0.1 mL/min under max pressure
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Weight: 52g (brass version) / 48g (stainless steel)
- Dimensions: 30mm(L) × 12mm(Dia) body, 16mm hex size
- IP rating: IP40 (dust protected)
Zero-pressure-loss quick connector featuring tool-free installation with positive click engagement. Precision-machined with double O-ring seals and brass collet for vibration-resistant tube retention. Optional 316L stainless steel version available for corrosive environments.
Typical Applications:
- Modular pneumatic assembly lines
- Robotic end-effector tool changers
- CNC machine coolant line connections
- Semiconductor vacuum handling systems
- Mobile hydraulic test benches
Installation protocol:
Cut tubing square (max 0.5° angle tolerance), insert fully until audible click.
For stainless steel version, apply thread sealant on male threads.
Requires 40μm filtered air/oil mist (ISO 8573-1 Class 4.4.2).
| Property | Property Value |
|---|---|
| sku | APU12 |
