Airtac APV L-Type 2-Port Connector APV14
$5.91
Regular price
$13.41
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
APV14
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、This series of connectors is entirely copper-free, making it directly applicable in copper-restricted environments;
2、Available in multiple specifications and models, extensively compatible with various pneumatic systems;
3、Optimized flow design achieves pressure drop equivalent to tubing inner diameter, ensuring full-bore flow capacity;
4、Features tool-free plug-and-pull operation with triple-lock collet mechanism for secure tubing retention and vibration resistance.
Category: L-Pattern Two-Way Connectors , Brand: AIRTAC , Series: APV （Note: This translation incorporates enhanced technical terminology while maintaining key specifications. The phrase "triple-lock collet mechanism" reflects common engineering terms for secure tubing connections. "Full-bore flow capacity" emphasizes hydraulic performance characteristics. "Copper-restricted" is preferred over "copper-free" to align with industrial standards documentation.）
Installation protocol:
Apply 2-3 wraps of PTFE tape on male threads (grade B1). Tighten to 1.2-1.6 N·m torque.
For vertical downward ports, install drip leg before connection. Test at 0.8MPa for 3min post-install.
2、Available in multiple specifications and models, extensively compatible with various pneumatic systems;
3、Optimized flow design achieves pressure drop equivalent to tubing inner diameter, ensuring full-bore flow capacity;
4、Features tool-free plug-and-pull operation with triple-lock collet mechanism for secure tubing retention and vibration resistance.
Category: L-Pattern Two-Way Connectors , Brand: AIRTAC , Series: APV （Note: This translation incorporates enhanced technical terminology while maintaining key specifications. The phrase "triple-lock collet mechanism" reflects common engineering terms for secure tubing connections. "Full-bore flow capacity" emphasizes hydraulic performance characteristics. "Copper-restricted" is preferred over "copper-free" to align with industrial standards documentation.）
AirTAC APV L-Type Two-Way Fitting APV14 Technical Details
- Model: APV14-L (L-shaped configuration)
- Thread type: PT1/4 (BSPP) female threads both ends
- Alternative thread options: NPT1/4, G1/4 available on request
- Material: Glass fiber reinforced PBT (30% GF)
- Seal material: NBR (standard), optional FKM for chemical resistance
- Max working pressure: 1.5 MPa (217 PSI)
- Burst pressure: ≥4.5 MPa
- Temperature range: -20℃ to 80℃ (continuous use)
- Peak temperature tolerance: 100℃ (intermittent)
- Flow coefficient (Cv): 0.65
- Weight: 22g ±1g (without packaging)
- Dimensions: 28mm(L) × 21mm(W) × 21mm(H)
- Surface finish: Mold-textured anti-scratch surface
- Certifications: RoHS compliant, REACH SVHC-free
90° angled pneumatic connector with precision-molded internal flow channels, engineered for minimal pressure drop (ΔP ≤0.02MPa @ 0.7MPa). Features dual O-ring seals with 360° rotation capability post-installation. Compatible with ISO 15407-1 standard actuators.
Primary Applications:
- Space-constrained pneumatic circuit layouts in robotics
- Modular assembly systems requiring quick-connect solutions
- Medical equipment pneumatic manifolds
- Packaging machine tooling plate connections
- Semiconductor wafer handling vacuum line transitions
Installation protocol:
Apply 2-3 wraps of PTFE tape on male threads (grade B1). Tighten to 1.2-1.6 N·m torque.
For vertical downward ports, install drip leg before connection. Test at 0.8MPa for 3min post-install.
| Property | Property Value |
|---|---|
| sku | APV14 |
