Airtac APV L-Type 2-Port Connector APV8
2、Available in multiple specifications and models, extensively compatible with various pneumatic systems;
3、Optimized flow design achieves pressure drop equivalent to tubing inner diameter, ensuring full-bore flow capacity;
4、Features tool-free plug-and-pull operation with triple-lock collet mechanism for secure tubing retention and vibration resistance.
Category: L-Pattern Two-Way Connectors , Brand: AIRTAC , Series: APV （Note: This translation incorporates enhanced technical terminology while maintaining key specifications. The phrase "triple-lock collet mechanism" reflects common engineering terms for secure tubing connections. "Full-bore flow capacity" emphasizes hydraulic performance characteristics. "Copper-restricted" is preferred over "copper-free" to align with industrial standards documentation.）
AirTAC APV L-Type Elbow Fitting APV8 Technical Details
- Model: APV8-L (Right Angle Threaded Connector)
- Type: L-shaped 2-way pneumatic elbow fitting
- Thread standard: PT1/8 (BSPP) female threads both ends
- Alternative thread options: NPT1/8 available on request
- Material: Brass with nickel-plated surface (CuZn39Pb3)
- Operating pressure: 0.05-1.0 MPa
- Burst pressure: ≥3.0 MPa
- Temperature range: -20℃ to 80℃
- Seal type: Integral O-ring (NBR rubber)
- Flow coefficient (Cv): 0.6
- Weight: 12.5g ±0.3g
- Dimensions: 18mm(Length) × 16mm(Width) × 21mm(Height)
- Surface roughness: Ra ≤1.6μm
- Vibration resistance: 10-55Hz, 1.5mm amplitude
Precision-machined L-shaped pneumatic connector featuring 90° flow direction change with minimal pressure drop. The compact nickel-plated brass construction resists corrosion and galling during repeated installations. Pre-installed EPDM O-ring ensures leak-free connections up to 145 psi.
- Space-constrained pneumatic circuit layouts
- Robotic end-effector air supply routing
- Modular pneumatic manifold systems
- CNC machine tool pneumatic cabinets
- Semiconductor handling equipment
Installation protocol:
Apply thread sealant only to male threads (not female ports).
Tighten 1.25-1.75 rotations past hand-tight position.
Maximum torque: 1.2N·m. Avoid overtightening to prevent port deformation.
