Airtac APX Y-Type Tee Fitting APX10-01
2. Comprehensive model range with multiple specifications, engineered for versatile integration across pneumatic systems;
3. Optimized flow dynamics achieve full-bore performance matching tubing inner diameter capacity;
4. Tool-free push-to-connect mechanism enables rapid installation/removal, with robust tubing retention for secure long-term operation.
Category: Y-Type Tee Fittings | Brand: AirTAC | Series: APX
AirTAC APX Y-Type Tee Joint APX10-01 Technical Specifications
- Model: APX10-01
- Type: Y-shaped pneumatic tee connector (equal distribution)
- Thread standard: PT1/8 (BSPP) female threads
- Alternative thread options: NPT1/8 available on request
- Max working pressure: 1.0 MPa (145 psi)
- Proof pressure: 1.5 MPa
- Burst pressure: 3.0 MPa
- Operating temperature: -20℃ to 80℃ (-4°F to 176°F)
- Body material: Nickel-plated brass C3604
- Seal material: Oil-resistant NBR (Nitrile rubber)
- Flow coefficient (Cv): 0.45
- Weight: 28g ±1g
- Dimensions: 30mm (L) × 20mm (W) × 20mm (H)
- Surface roughness: Ra ≤3.2μm
- Vibration resistance: 10-55Hz, 1.5mm amplitude
Precision-engineered Y-connector featuring a 120° branch angle for balanced flow distribution in pneumatic systems. The electroplated nickel coating provides enhanced corrosion resistance, while the chamfered internal passages minimize turbulent flow. Compatible with ISO 1179-1 standards for industrial fittings.
- Pneumatic circuit branching in automation equipment
- Air tool manifold connections
- Packaging machine air distribution networks
- Laboratory pneumatic control systems
- Robotic actuator air supply splitting
Installation guidelines:
Apply 2-3 wraps of PTFE tape on male threads (do not over-tighten - max torque 1.2N·m).
For vertical mounting, position main flow port downward to prevent debris accumulation.
Compatible with Ø6mm and Ø8mm tubing when used with corresponding adapters.
| Property | Property Value |
|---|---|
| sku | APX10-01 |
